Hoffman CSD30248LGEMC, Concept™ Wall-Mount Emc Encl, 30.00X24.00X8.00

Hoffman CSD30248LGEMC, Concept™ Wall-Mount Emc Encl, 30.00X24.00X8.00

Item #: WBB1456343

Not Yet Rated

Enter zip code for delivery date estimate

Shipping to 10465 change

$1,761.00 up to 24% OFF

Price: $1,341.00

$223.50 / month suggested monthly payments with 6 mo. special financing on the purchase of $1,341.00 or save 5% on purchase.

Quantity

Customers Also Viewed

Hoffman CSD30248LGEMC, Concept™ Wall-Mount Emc Encl, 30.00X24.00X8.00

Use stylish CONCEPT™ EMC Enclosures with their convenient quarter-turn latches in indoor or outdoor applications to contain stray electromagnetic interference (EMI) signals produced by internal components and to shield those components from external EMI/RFI interference.

Features:
  • 14, 16 or 18 gauge steel (see table)
  • Seams continuously welded and ground smooth
  • Minimum width body flange provides maximum door opening
  • External formed body flange
  • Panel mounting studs fit optional CONCEPT panels and other accessories
  • Mounting holes in back of body for direct mounting or for optional external mounting brackets
  • Hidden 210-degree hinges
  • Removable corner-formed door
  • Hinge mounting brackets for wire management or optional accessories
  • Stainless steel spring finger EMI/RFI gasket
  • Quarter-turn latches
  • Body grounding stud
  • Door bars provided for wire management and bonding
  • Furnished hardware kit consists of panel mounting nuts, grounding hardware and sealing washers
  • Simple easy-to-remove and install hinge pins with built-in captivation clip
  • High-torque threadless studs and fasteners on door
  • Illustrated instruction sheet

Product Specifications

  • BRANDHoffman®
  • MANUFACTURERS PART NUMBERCSD30248LGEMC
  • TYPE4/12
  • CONSTRUCTIONSteel
  • J MM127
  • J INCHES5
  • DOOR GAUGE14
  • PANEL SIZE D X E MM716 x 564
  • MOUNTING G X H MM724 x 572
  • PANEL GAUGE28.20 x 22.20
  • MOUNTING G X H INCHES28.50 x 22.50
  • DESCRIPTIONWall Mount EMC Enclosure
  • COLORLight Gray
  • A X B X C MM762 x 610 x 203
  • CONDUCTIVE PANELCP3024G
  • A X B X C INCHES30.00 x 24.00 x 8.00
  • LATCHES QTY.2
  • LATCHES STYLEQuarter-Turn
  • BODY GAUGE16
  • CONCEPT PANELCP3024
