RIB® Enclosed Relay/AC Sensor RIBHX24BF-N4, 20A, SPST-NO, 24VAC/DC, NEMA 4 HSG
These Current Sensor / Relay combination units control and sense up to 20 Amp loads, without the use of an external current ring, greatly reducing installation time. Models are available with fixed, or adjustable current sensing trigger points, or with voltage out.
These Current Sensor / Relay combination units control and sense up to 20 Amp loads, without the use of an external current ring, greatly reducing installation time. Models are available with fixed, or adjustable current sensing trigger points, or with voltage out.
Weights & Dimensions
- Width 2.8 in
- Length 1.7 in
- Height 1.5 in
- Wire Size 16 in
Product Details
- Operating Temperature -30° To 140°F
- Humidity Range 5 To 95 Percent (Noncondensing)
- Voltage 24VAC/DC V
- Expected Relay Life 10 Million Cycles Minimum Mechanical
- Description Enclosed Relay/AC Sensor
- Number of Relays 1
- Amperage 20 A
- Wire Rating 600V
- Brand RIB
- Threshold Fixed
- Manufacturers Part Number RIBHX24BF-N4
- Contact Type SPST-N/O
Warranty
- Warranty 1 yr
Compliance & Certifications
- Certifications UL Listed
Customer Review
Product Q & A
There are no questions for this product.
RIB® Enclosed Relay/AC Sensor RIBHX24BF-N4, 20A, SPST-NO, 24VAC/DC, NEMA 4 HSG
$54.95
