NACHI Radial Ball Bearing 6222-2RS, Double Sealed, 110MM Bore, 200MM OD
Radial Ball Bearing has moderate load-carrying capacity in both radial and axial directions and is good for high speed and high accuracy. Rubber seal or metal shield on one or both sides of the bearing helps keep out dirt and contaminants. In case two seals or two shields are used, the bearing is lubricated by grease for its life when manufactured. The bearing with 10 to 75 mm bore (6000 to 6300 series) & 10 to 50 (6800 & 6900 series) improves reliability with newly designed seal and shield, and suitable grease. Quiet rotation is expected by improved accuracy of components, and saving cost and energy is also expected by lower power loss provided by low and stable running torque.
Radial Ball Bearing has moderate load-carrying capacity in both radial and axial directions and is good for high speed and high accuracy. Rubber seal or metal shield on one or both sides of the bearing helps keep out dirt and contaminants. In case two seals or two shields are used, the bearing is lubricated by grease for its life when manufactured. The bearing with 10 to 75 mm bore (6000 to 6300 series) & 10 to 50 (6800 & 6900 series) improves reliability with newly designed seal and shield, and suitable grease. Quiet rotation is expected by improved accuracy of components, and saving cost and energy is also expected by lower power loss provided by low and stable running torque.
Weights & Dimensions
- Tolerance ISO Class 0
- Outside Dimension 200 mm
- Width 38 mm
- Static Load Rating 117,000 N
- Bore 110 in
Product Details
- Bearing Style Radial Ball Bearings
- Dynamic Load Rating (N) 144,000
- Description Radial Ball Bearing
- Brand Nachi
- Bearing Type Double Sealed
- Series 6200
- Manufacturers Part Number 6222-2RS
- Radial Clearance C3
- Grease Max Speed 2,100 rpm
Customer Review
Product Q & A
There are no questions for this product.

Nachi Radial Ball Bearing 6222-2RS, Double Sealed, 110MM Bore, 200MM OD
$300.95
