Bimba-Mead Pilot Solenoid Valve M4V310-08-24VAC, 5 Port, 2 Pos, Single, 1/4" NPT, 24VAC, Cv=1.4
M4V310-08 piloted single solenoid valves are 4-way, 1/4 in NPT port, spool style valves. They are stackable and provide a 2-position, normally closed, spring return operation. The M4V310-08 series valves can be used in individual valve applications or multiple valves can be assembled together on a manifold to share supply air which simplifies the piping. They are compatible with the M300M series manifolds. The DIN connector includes an LED indicator. Valves equipped with a turning manual override.
M4V310-08 piloted single solenoid valves are 4-way, 1/4 in NPT port, spool style valves. They are stackable and provide a 2-position, normally closed, spring return operation. The M4V310-08 series valves can be used in individual valve applications or multiple valves can be assembled together on a manifold to share supply air which simplifies the piping. They are compatible with the M300M series manifolds. The DIN connector includes an LED indicator. Valves equipped with a turning manual override.
- LENGTH INCHES 5-5/16
- WIDTH INCHES 1-1/16
- HEIGHT INCHES 2-23/32
- BRAND Bimba-Mead
- MANUFACTURERS PART NUMBER M4V310-08-24VAC
- TYPE 5 Port 2 Position
- TEMPERATURE RANGE 23∼140°F
- PRESSURE 22 to 120 PSI
- LUBRICATION Not Required
- ACTUATION Internally Piloted
- MEDIA Air
- INSULATION Class F
- FLOW Cv = 1.39
- PORT SIZE 1/4" NPT
- POWER CONSUMPTION 3.5 VA
- PROTECTION IP65 (DIN 40050)
- POWER CONNECTION DIN / LED Connector
- VOLTAGE RANGE ±10%
