Bimba-Mead Pilot Solenoid Valve M4V310-08-24VDC, 5 Port, 2 Pos, Single, 1/4" NPT, 24VDC, Cv=1.4

Bimba-Mead Pilot Solenoid Valve M4V310-08-24VDC, 5 Port, 2 Pos, Single, 1/4" NPT, 24VDC, Cv=1.4

Item #: WBB571682

Not Yet Rated

Enter zip code for delivery date estimate

Shipping to 10465 change

Price: $52.95

Save $2.65 with 5% off when you use your Global Industrial Credit Card.

Quantity

Customers Also Viewed

Bimba-Mead Pilot Solenoid Valve M4V310-08-24VDC, 5 Port, 2 Pos, Single, 1/4" NPT, 24VDC, Cv=1.4

M4V310-08 piloted single solenoid valves are 4-way, 1/4 in NPT port, spool style valves. They are stackable and provide a 2-position, normally closed, spring return operation. The M4V310-08 series valves can be used in individual valve applications or multiple valves can be assembled together on a manifold to share supply air which simplifies the piping. They are compatible with the M300M series manifolds. The DIN connector includes an LED indicator. Valves equipped with a turning manual override.

  • LENGTH INCHES 5-5/16
  • WIDTH INCHES 1-1/16
  • HEIGHT INCHES 2-23/32
  • BRAND Bimba-Mead
  • MANUFACTURERS PART NUMBER M4V310-08-24VDC
  • TYPE 5 Port 2 Position
  • TEMPERATURE RANGE 23∼140°F
  • PRESSURE 22 to 120 PSI
  • LUBRICATION Not Required
  • ACTUATION Internally Piloted
  • MEDIA Air
  • INSULATION Class F
  • FLOW Cv = 1.39
  • PORT SIZE 1/4" NPT
  • POWER CONSUMPTION 3.0 W
  • PROTECTION IP65 (DIN 40050)
  • POWER CONNECTION DIN / LED Connector
  • VOLTAGE RANGE ±10%
