Series 300 Nipple - 1/4" Hose Barb (ARO 210 Standard)
Series 300 couplings offer high flow and require only a low connection force, which ensures a safe working environment. Male threads on the couplings and nipples feature pre-applied thread sealant. The Series 300 vented safety version is disconnected in two stages in order to vent the coupling and minimize the risk of sudden component separation, which has the potential to cause operation injury. Full automatic operation ensures easy handling. The vented safety version complies with ISO Standard 4414 and EN 983.
Series 300 couplings offer high flow and require only a low connection force, which ensures a safe working environment. Male threads on the couplings and nipples feature pre-applied thread sealant. The Series 300 vented safety version is disconnected in two stages in order to vent the coupling and minimize the risk of sudden component separation, which has the potential to cause operation injury. Full automatic operation ensures easy handling. The vented safety version complies with ISO Standard 4414 and EN 983.
- Full Automatic Operation
- Strong And Durable
- High Flow Capacity
Weights & Dimensions
- Nominal Flow Diameter 7/32 in
- Body Size 1/4 in
Product Details
- CFM 36.6 CFM
- Connection Force 70.7 N
- Temperature Range -4 +212 °F
- Interchange ARO (1/4)
- Brand Cejn
- Connection Configuration 1/4 Hose Barb
- PSI 232 psi
- Series 300
- Material Hardened Zinc Plated Steel
- Max Operating PSI 232 psi
- Manufacturers Part Number 10-300-5002
- Min Burst Pressure 2030 psi
- Respirator Connection Type 1/4 Hose Barb
Compliance & Certifications
- Certifications ARO (1/4)
