Worldwide Electric SMR3-15/1, Shaft Mount Reducer, Size 3, 15:1 Ratio, 2-3/16" Tapered Bore

Worldwide HdRF175-30/1-L-56C Cast Iron Right Angle Worm Gear Reducer 30:1 Ratio 56C Frame Cast Iron Worm Gear Reducers are available in center distances 1.33 - 3.25 inches in ratio's from 5:1 to 60:1. The units have a one piece #Fc20 all cast iron housing, NEMA motor quill style input flanges or shaft inputs, come pre-filled with synthetic oil and have a 1 year warranty. Features: Tapered roller bearings on the input and output shafts Embedded double-lip oil seals Anti-rust primer applied inside and outside of the gearbox Air dry special black paint

Worldwide Electric SMR8-25/1, Shaft Mount Reducer, Size 8, 25:1 Ratio, 4 7/16" Tapered Bore The "Original" Shaft Mount Reducer, Box size 8, 25:1 ratio, 4-7/16" Output bore (max.), Tapered bushing type (Tapered bushing not included); Torque arm included; 2 year warranty; ; dimensional drop-in for a Dodge TXT series; shafts and gears manufactured from high grade steel, case hardened and precision ground to A.G.M.A. standards; metal reinforced double lip, spring loaded oil seals.

Worldwide Electric SMR6-15/1, Shaft Mount Reducer, Size 6, 15:1 Ratio, 3 7/16" Tapered Bore The "Original" Shaft Mount Reducer, Box size 6, 15:1 ratio, 3-7/16" Output bore (max.), Tapered bushing type (Tapered bushing not included); Torque arm included; 2 year warranty; dimensional drop-in for a Dodge TXT series; shafts and gears manufactured from high grade steel, case hardened and precision ground to A.G.M.A. standards; metal reinforced double lip, spring loaded oil seals.

Worldwide Electric SMR2-25/1, Shaft Mount Reducer, Size 2, 25:1 Ratio, 1 15/16" Tapered Bore The "Original" Shaft Mount Reducer, Box size 2, 25:1 ratio, 1-15/16" Output bore (max.), Tapered bushing type (Tapered bushing not included); Torque arm included; 2 year warranty; ; dimensional drop-in for a Dodge TXT series; shafts and gears manufactured from high grade steel, case hardened and precision ground to A.G.M.A. standards; metal reinforced double lip, spring loaded oil seals.

Worldwide Electric SMR7-25/1, Shaft Mount Reducer, Size 7, 25:1 Ratio, 3 15/16" Tapered Bore The "Original" Shaft Mount Reducer, Box size 7, 25:1 ratio, 3-15/16" Output bore (max.), Tapered bushing type (Tapered bushing not included); Torque arm included; 2 year warranty; ; dimensional drop-in for a Dodge TXT series; shafts and gears manufactured from high grade steel, case hardened and precision ground to A.G.M.A. standards; metal reinforced double lip, spring loaded oil seals.
