Functions, Programming and Diagnostics
- Bluetooth 4.0 communication (standard)
- SafePace® Pro Management Software application
- Miles per hour or Kilometer per hour selectable
- Add 24/7 365-day unlimited programming and scheduling
- Display On/Stealth Modes (in stealth mode, speed is not displayed but data is collected)
- Display Minimum Speed / Display Maximum Speed
- Digit Flashing Speed Threshold (digits flash above selected speed)
- Speed Violator Strobe (pulsing strobe flashes with digits or alone above display maximum speed)
Enclosure
- 12 gauge aluminum
- Flat black powder coated front, light gray powder coated body
- Weatherproof, NEA 4X-12, IP65 level compliant, non-sealed and ventilated
- 25" aluminum protective cover
- White HIP reflective sheeting on sign face, black text, MUTCD conforming
- Operating temperatures: -40°F/-40°C to 185°F/85°C
- Conformal coating on all circuit boards
- Standard banding brackets or optional universal mounting bracket system (bracket, locking plate, key and pole-mount plate) for mounting
Display
- Digit Size: 11"H x 5.6"W
- 196 Amber 5 mm LEDs, 15°, luminous intensity (4180-8200/LED)
- Speed Violator Strobe: 12 White 5 mm LEDs, 15°, luminous intensity (5680-8200/LED)
- Display Brightness, 11,000 nits (cdm) maximum, 550 nits (cdm) at night
- Ambient light sensor and automatic brightness adjustment
Power
- Power input: AC100-240 VAC, 12 VDC
- Built in ambient light sensing and automatic brightness adjustment
Radar
- Doppler Internal Radar (FCC Approved)
- 5 mW maximum Radar RF out, 24.125 GHz or 24.200 GHz Radar f-center
- Up to 800 ft pickup distance
