Acudor Glass Fiber Reinforced Gypsum Ceiling Access Door, 24"W x 24"H Door Opening

Walk Through Access Door for access to duct work & air handling units. Aluminum Frame w/ Galvanized Steel Door Panel. " L "Handles ship loose with the unit. 1-15/16" (w) x 1-1/2" deep extruded aluminum frame w/ mitred corners. 2 Latches. Mill Finish. 32-1/2"W x 38-1/2"H Outside Flange Dimensions. 30 W x 1-5/8"D x 36 H Return Flange Dimensions.

The plastic access panel is designed to provide easy access to walls & ceilings. The high impact styrene plastic with U.V. stabilizers will not fade or corrode. All units except the 14x29 are hinged with a removable door panel feature.

Steel, Fire Rated Access Door for Walls & Ceilings. With an insulated door panel, this unit has a UL 90-minute label for walls with a maximum temperature rise of 250 degrees after 30 minutes. This unit is also test up to 3 hours in ceiling applications and carries a Warnock Hersey rating for ceilings. Self Latching, 1 Latch. White Finish. 26"W x 26"H Outside Flange Dimensions. 24-1/8"W x 24-1/8"D x 2-9/16"H Return Flange Dimensions.

Constructed of a 24 gauge galvanized steel double panel door and frame with mill finish for long lasting durability. 1/8" thick x 1/2"W closed cell neoprene gasketing between insulated door and frame assures tight seal without obstruction in air system. Frame includes 5/8" notched knock over tabs. Door panel filled with 2" fiberglass insulation compressed into 1" and includes aluminum continuous piano hinge. 24" W x 24" H outside flange dimensions. 22-3/4" W x 22-3/4" D x 5/8" H return flange dimensions. Color finish is Silver . Number of latches is 2 .

Stainless Steel Access Door that has been tested for air infiltration & water penetration. The door and frame are fully welded & gasketed. This access door is ideal for use in laboratories, clean rooms, operating rooms, etc... Comes in type 304 stainless steel with #4 satin polish finish. 2 Latches. Stainless Steel Finish. 14-3/4"W x 14-3/4"H Outside Flange Dimensions. 12"W x 12"D x 2"H Return Flange Dimensions.
