Hoffman ANADFK, Swing-Out Panel Kit, Fits Type 12 Encl., Steel/Zinc
Kits allow mounting standard Hoffman junction box and NEMA style panels (purchase separately) near the front of the enclosure for easy access to or reading of gauges, switches, pilot lights and other components. Kits consist of heavy-gauge brackets and hinges which are easily installed by drilling small holes in the sides of the enclosure and bolting the brackets in place. External screws are stainless steel; internal components are plated steel. All mounting hardware and instructions are provided. Sealing washers ensure the enclosure will meet original JIC or NEMA standards after installation. Swing-Out Panel Kits do not fit single-door disconnect enclosures.
Share
Spec Sheet
Hoffman ANADFK, Swing-Out Panel Kit, Fits Type 12 Encl., Steel/Zinc
Write a Review
|
Questions & Answers (0)
Product Description
PRICE
$159.95
1
1
Ships in 5 Business Days
Add or Change Zip Code(s)
Easy online or call-in returns. Read return policy
Specifications
Weights & Dimensions
| Max Load | 100 lbs |
Product Details
| Enclosure Type | 12 |
| Material | Steel |
| Description | Wall-Mount Enclosure Kit |
| Color | Silver |
| Manufacturers Part Number | ANADFK |
| For Use With | One-door Type 4, 12 and 13 Enclosures where A x B is 12.00 x 12.00 in. or larger |
| Fits | Type 12 Enclosure |
| Brand | Hoffman |
