HORIZONTAL OR VERTICAL DISCHARGE FAN FORCED SUSPENDED UNIT HEATERS
5,000 Watt Heater 208V
Suspended unit heaters can be installed for either vertical or horizontal discharge applications. Discharge fan forced heaters have an 18 gauge steel cabinet housing with a long-lasting powder coat finish. These fan forced heaters feature spiral fin steel element with continuously brazed steel fins that allow side draw through airflow. Fan forced heaters include individually adjustable louvers for directional control of air flow up to 15° from straight horizontal position. The automatic reset limit de-energizes these heaters if over-heating occurs. Fan over-ride purges electric heaters of residual heat at shutdown. Control compartment housing has a hinged and latched access door that allows access to wiring for installation and maintenance. Suspended unit heaters feature a totally enclosed 1-speed permanently lubricated thermally protected motor with unit bearings. UL approved. 1 Year Limited Warranty.
5,000 Watt Heater 208V
Suspended unit heaters can be installed for either vertical or horizontal discharge applications. Discharge fan forced heaters have an 18 gauge steel cabinet housing with a long-lasting powder coat finish. These fan forced heaters feature spiral fin steel element with continuously brazed steel fins that allow side draw through airflow. Fan forced heaters include individually adjustable louvers for directional control of air flow up to 15° from straight horizontal position. The automatic reset limit de-energizes these heaters if over-heating occurs. Fan over-ride purges electric heaters of residual heat at shutdown. Control compartment housing has a hinged and latched access door that allows access to wiring for installation and maintenance. Suspended unit heaters feature a totally enclosed 1-speed permanently lubricated thermally protected motor with unit bearings. UL approved. 1 Year Limited Warranty.
Weights & Dimensions
- Depth 6-1/2 in
- Width 14-1/2 in
- Height 17-3/4 in
- Weight 25 lbs
Product Details
- Kilowatts 5 kW
- Voltage 208 V
- Assembly Required Assembled
- BTU High 17100
- Discharge Horizontal or Vertical
- Phase 1 or 3
- CFM High 400 CFM
- Watts High 5000 W
- Amps High 24.1 A
- Brand TPI
- Material Steel
- Manufacturers Part Number F2F5105N
- Color Family Gray Powder Coat
- Amps Low 13.9 A
⚌
Photo/Video Gallery
Customer Review
Product Q & A
There are no questions for this product.
Accessories
$107.95
Warranty
This product has a 12-month manufacturer's limited warranty for parts and a 12-month manufacturer's limited warranty for labor. Protect your purchase beyond the manufacturer's limited warranty.
TPI Unit Heater, Horizontal or Vertical Discharge F2F5105N - 5000W 208V 1/3 PH
