Features:
- 1/2-125 HP
- 3600, 1800, 1200 RPM
- 208-230/460 Volt, 60 Hz
- 190/380 Volt, 50 Hz
- Open Drip Proof (ODP) Enclosure
- Rolled Steel Frame (1/2-50 HP) – Cast Iron Frame (60-100 HP)
- IP23 Protection
- 1.15 SF (1.0 SF for 50 Hz Applications)
- Class F Insulation
- Rigid Base (56C-Face with Removable Base)
- Premium Efficiency
- Class B Temperature Rise
- Inverter Duty, 10:1 CT / 20:1 VT (1.0 SF)
- Inverter Grade Magnet Wire Meets or Exceeds NEMA MG-1 Part 31
- Pre-Drilled and Tapped Drive Endbells on 143T Frame and Up to Accept Inpro® Current Diverter Rings; No Machining Required, Simple and Easy Installation
- Exclusive Double Vacuum Pressure Impregnation (VPI) Insulation System
- Double Drilled Feet to Accommodate Mounting Flexibility (143T-404T)
- 254T and larger are suitable for F1 to F2 conversion
