Williams® Plate Reaction Torque Multiplier, 2200 ft-lbs Capacity

Proto® Torque Multiplier 2200 ft-lbs, 19-19/32" Long, W/NIST Cert Maximum rated input: 162 ft-lbs (220 Nm). Maximum rated output: 2200 ft-lbs (2983 Nm). Standard torque accuracy is +/- 5% of reading. Reaction system: tubular reaction bar. Gear system: two stage planetary. Angle of turn protractor: 5° increments. Anti-backlash device: self-contained, 3 position. Certification documents traceable to N.I.S.T. (National Institute of Standards and Technology).

Proto® Torque Multiplier 2200 ft-lbs, 19-19/32" Long Maximum rated input: 162 ft-lbs (220 Nm). Maximum rated output: 2200 ft-lbs (2983 Nm). Standard torque accuracy is +/- 5% of reading. Reaction system: tubular reaction bar. Gear system: two stage planetary. Angle of turn protractor: 5° increments. Anti-backlash device: self-contained, 3 position.

Features: Strong-Steel housing protects the internal gears against impacts Strong-handle for safer support Ideal for use in building and maintenance machinery and in the automotive industry where requires big torques appliances and with reduced works areas Torque ratio: 1:3.5 Female drive: 3/4" Male drive: 3/4" Maximum torque: 286 ft-lb Input, 1000 ft-lb Output Length: 2-7/16"

Proto® Torque Multiplier 3200 ft-lbs, 19-19/32" Long Maximum rated input: 173 ft-lbs (235 Nm). Maximum rated output: 3200 ft-lbs (4338 Nm). Standard torque accuracy is +/- 5% of reading. Reaction system: tubular reaction bar. Gear system: two stage planetary. Angle of turn protractor: 5° increments. Anti-backlash device: self-contained, 3 position.

The wrench that does not require releasing tension after use. 100% Italian-made, it is ideal for controlled tightening of screws/bolts. Features: Zero-Reset Technology: Based on higher-performance materials and improved heat treatment of both the spring and the component parts of the adjustment system, the wrench no longer requires releasing tension after use. Easy Settings: The graduated vernier scale allows minimum interval fractions to be set up (in tenths of lbf.ft). 100% Italian-Made: Entirely designed and manufactured in Italy, assembled, tested and certified at Beta's ...
