Marathon Motors Severe Duty Motor, W601, 405THFS9040, 100HP, 575V, 1800RPM, 3PH, 405T FR, TEFC

Actual product may differ from image shown

Marathon Motors Severe Duty Motor, W601, 405THFS9040, 100HP, 575V, 1800RPM, 3PH, 405T FR, TEFC

Item #: WBB870060

Not Yet Rated

Free Shipping

Enter zip code for delivery date estimate

Shipping to 10465 change

Price: $7,490.00

$1,248.33/mo suggested payments with 6 month special financing OR Save 5%on Purchase.

Quantity

Customers Also Viewed

Marathon Motors Severe Duty Motor, W601, 405THFS9040, 100HP, 575V, 1800RPM, 3PH, 405T FR, TEFC

Marathon's 1800 Rpm, line of 575 Volts, Severe Duty Neman Premium XRI Duty IEEE-841 Hazardous Duty Motor are available in TEFC construction. Horsepower sizes available from stock range from 1 HP through 200 HP.

  • HORSEPOWER 100
  • ENCLOSURE TEFC
  • FRAME 405T
  • BRAND Marathon Motors
  • MOUNTING Rigid
  • MOTOR RPM 60Hz 1800
  • RPM 1800
  • PHASE 3
  • VOLTAGE 575
  • SERVICE FACTOR 1.15
  • AMBIENT TEMP C 40
  • ENCLOSURE TYPE Totally Enclosed
  • OPPOSITE END BEARING 6313
  • WEIGHT 1354
  • UL Recognized Construction
  • CSA Y
  • DUTY Continuous
  • MANUFACTURERS PART NUMBER W601
  • RPM RANGE 1701-1800
  • INSULATION CLASS F
  • HAZARDOUS LOCATION DIVISION 2 T2B
  • INVERTER SPEED RANGE Constant 10:1
  • FL AMPS 90.5
  • OPPOSITE END BEARING SIZE 6313
  • DRIVE END BEARING SIZE 6316
  • ASSEMBLY F1 (F2 Modification Available)
  • ORIENTATION Horizontal
  • BEARING-DRIVE-END 6316
  • IP CODE 56
  • STARTING TYPE Line or Inverter
  • NEMA DESIGN B
  • CE Y
  • FL EFFICIENCY 95.4
  • is_motor Yes
  • KVA-CODE F
  • 60 HERTZ kW 75
  • 60 HERTZ RPMS 1800
  • MODEL NUMBER 405THFS9040
