Crosby A-1337 G100 Chain Connecting Link, Lok-A-Loy 3/4", 35300 LBS WLL

Entire clip is Galvanized to resist corrosive and rusting action. Based on the catalog breaking strength of wire rope, Crosby wire rope clips have an efficiency rating of 80% for 3/16"-7/8" sizes, and 90% for sizes 1" through 1-1/2". Bolts are an integral part of the saddle. Nuts can be installed in such a way as to enable the operator to swing the wrench in a full arc for fast installation. All sizes have forged steel saddles. All Clips are individually bagged or tagged with proper application instructions and warning information. Meets or exceeds all requirements of ASME B30.26 ...

Used for flemish eye wire rope splicing Designed for low temperature toughness Resists cracking when swaged (equals or exceeds stainless steel sleeves) Special processed low carbon steel Can be stamped after swaging for identification purposes (view product specifications for full details) Recommended for use with 6x19 or 6x37, IPS, XIP or XXIP, RRL, FC or IWRC wire rope

Meets the performance requirements of Federal Specifications FF-T-791b, Type 1, Form 1, Class 8, and ASTM F-1145, except for those provisions required of the contractor End fittings are Quenched and Tempered or Normalized, bodies heat treated by normalizing Hot-dip galvanized steel Turnbuckle eyes are forged elongated, by design, to maximize easy attachment in system and minimize stress in the eye--for turnbuckle sizes 1/4" through 2-1/2", a shackle one size smaller can be reeved through eye Forged jaw ends are fitted with bolts and nuts on size 1/4" - 5/8", and pins and cotter on sizes ...

Forged alloy steel, Quenched and Tempered, load-rated Eye fitting accepts Crosby A-1337 Lok-A-Loy 10 Connecting Links for connection to chain slings Individually proof-tested to 2-1/2 times the Working Load Limit with certification Product Identification Code (PIC) for material traceability, along with the size and the name Crosby Suitable for use with Grade 100 and Grade 80 chain Fatigue rated at 1-1/2 times the Working Load Limit at 20,000 cycles Large throat opening for fitting over large objects, no latch kit by design Hook can be tip loaded at a reduced Working Load Limit, see ...

Eliminates the potential breaking off of the tail due to fatigue…tail is secured by base of clip and the wedge, left unharmed and available for reuse Eliminates the need for an extra piece of wire rope Dead end of wire rope is secured to wedge, which eliminates loss or "punch out" of the wedge Basket is cast steel and magnetic particle inspected Pin diameter and jaw opening allows wedge and socket to be used in conjunction with closed swage and spelter sockets 80% efficiency rating based on catalog strength of XXIP wire rope QUIC-CHECK markings are incorporated…the wire rope should pass ...
