Weights & Dimensions
| Length | 14.29 in |
| Width | 10.5 in |
| Height | 10-1/2 in |
| Weight | 24 lbs |
| Shaft Length | 0.5 in |
| Shaft Diameter | 0.5 in |
| Opposite End Bearing Size | 6203 |
| Drive End Bearing Size | 6203 |
| Length Less Shaft | 18.5 in |
Product Details
| Number of Speeds | 1 |
| Drive End Flange | Standard |
| Motor RPM 60 Hertz | 1140 rpm |
| Mounting Location | No Mounting |
| Phase | 3 |
| Manufacturers Part Number | CFM3036A |
| Enclosure | OPEN |
| Service Factor | 1 |
| Brand | Baldor-Reliance |
| Bearing Type | Ball |
| Insulation Class | F |
| Horsepower | 1/2 HP |
| Frame | 48YZ |
| Hertz | 60 Hz |
| Design Code | B |
| Rotation | CCW/CW ° |
| Thermal Protection | Automatic |
| Enclosure Type | Open/Drip Proof |
| Voltage | 208-230/460 V |
| Full Load Efficiency | 72 |
| Full Load Amps | 2.5-2.4/1.2 FLA |
| Duty | Continuous |
| Poles | 6 |
| Rated RPM | 1140 |
| Ambient Temperature | 60 °C |
| RPM Range | 1101-1200 rpm |
Compliance & Certifications
| Certifications | CSA; UR |
