Actual product may differ from image shown
$28,200.00 up to 36% OFF
Price: $18,011.00
Customers Also Viewed
Global Industrial™ Outdoor Ashtray, 1-1/2 Gallon, Black
Free Shipping
Features:
- Designed and manufactured and tested to exceed the IEEE 841-1994 standards for severe duty TEFC induction motors
- Premium efficiency copper windings using Baldor-Reliance ISR (Inverter Spike Resistant)® magnet wire comply with CEE efficiency guidelines
- Inpro Seal® on fan and drive end shaft extensions
- 2-part yellow epoxy oxide primer (inside & outside)
- Gray epoxy paint and corrosion resistant hardware
- Reduced noise, vibration and mechanical tolerances
- Final test and vibration results shipped with motor
Typical applications include petro-chemical, pulp and paper plants, mines and other installations requiring premium efficient motors manufactured and tested to rigid standards for severe duty service.
Weights & Dimensions
- Dimension C 40.98 in
- Weight 1968 lbs
Product Details
- RPM Range 3001-3600 rpm
- Voltage 460 V
- Frame 444TS
- Service Factor 1.15
- Horsepower 125 HP
- Class Insulation F
- Enclosure Type Totally Enclosed
- Is_Motor yes
- RPM 3570 rpm
- Enclosure TEFC
- Phase 3
- Full Load Efficiency 95
- Brand Baldor-Reliance
- Full Load Amps 137 FLA
- Hertz 60 Hz
- Manufacturers Part Number ECP84412T-4
