Hoffman ED1PBM1, Push Button Encl, 1Pb X 22.5Mm

Hoffman WF40LP, Weatherflo­™ Drive Encl W/2 6In Fan, 47.00X24.00X14.00, Type 3R WEATHERFLO™ Enclosures feature a forced-air ventilation system for cooling drives or other high-heat producing equipment in outdoor applications. Features: 16 and 14 gauge galvanized steel Largest two sizes constructed of aluminum

Hoffman A36D3012, Enclosure, Nema Type 9, 36.00X30.00X12.00, Steel/Gray For use in Class II Division 1 and 2 locations as defined in Article 500 of the National Electrical Code as having the presence of combustible dusts. 0.19-in. (5-mm), .25-in. (6-mm) and .38-in. (10-mm) steel plate. Ends are .38-in. (10-mm) steel plate to provide a minimum of 3.50 full threads for conduit sizes through 2.00 in. (51 mm). (Class II enclosures must have minimum of 3.50 full threads at all conduit entrances. NEMA requires conduit entrances to be in top and/or bottom of enclosure. Tapped holes for conduit ...

These Sloped Front Pushbutton Enclosures are designed to hold 30.5-mm or 22.5-mm pushbuttons and switches where slanted control surfaces are desired. Features: 14 gauge steel Seams continuously welded and ground smooth Captivated cover screws thread into sealed wells Grounding nut in body of enclosure Bonding provision on cover Oil-resistant gasket Factory stamped 4-way pushbutton holes Enclosures 7.25 x 6.25 x 6.75 in. (184 x 159 x 171 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit immediate removal External mounting brackets

Hoffman E30PBA, Push Button Encl, Sloped Front, 30Pb X 30.5Mm These Sloped Front Pushbutton Enclosures are designed to hold 30.5-mm or 22.5-mm pushbuttons and switches where slanted control surfaces are desired. Features: 14 gauge steel Seams continuously welded and ground smooth Captivated cover screws thread into sealed wells Grounding nut in body of enclosure Bonding provision on cover Oil-resistant gasket Factory stamped 4-way pushbutton holes Enclosures 7.25 x 6.25 x 6.75 in. (184 x 159 x 171 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit ...

Hoffman E4PBX, Push Button Encl, Extra Deep, 4Pb X 30.5Mm, 11.00 X 4.22 In. Extra-Deep Pushbutton Enclosures are designed to hold 30.5-mm and 22.5-mm pushbuttons and switches, with added depth to accommodate additional pushbutton contact blocks. Features: 16 or 14 gauge steel Seams continuously welded and ground smooth Captivated cover screws thread into sealed wells Grounding nut in body of enclosure Bonding provision on cover Oil-resistant gasket Factory stamped 4-way pushbutton holes Enclosures 6.00 x 4.00 x 4.75 in. (152 x 102 x 121 mm) and larger have internal detachable hinge to ...
