Walther Electric 332, Female Connector, 30/32A, 5P, 400Vac, 6 Hr, IP44, With Cable Gland

Walther Electric 332, Female Connector, 30/32A, 5P, 400Vac, 6 Hr, IP44, With Cable Gland

Item #: WBB2112792

Not Yet Rated

Enter zip code for delivery date estimate

Shipping to 10465 change

Price: $75.95

Save $3.80 with 5% off when you use your Global Industrial Credit Card.

Quantity

Customers Also Viewed

Walther Electric 332, Female Connector, 30/32A, 5P, 400Vac, 6 Hr, IP44, With Cable Gland

Features:

  • UL Listed and CSA certified.
  • Back shell has removable bell nozzle to accept adapter for liquid tight fittings.
  • Recessed female contacts – finger recessed to prevent touching.
  • Terminal identification – ground, neutral, phase – clearly marked.
  • Color coded by voltage-easy match-no errors.
  • Ground termination is positioned higher allowing for cable slack.
  • Solid brass pins. Low contact resistance high conductivity. Long lasting, reliable electrical contact.
  • Split contact sleeve with nickel plated steel springs. Provides optimum insertion/withdraw force and constant contact pressure liability. Also provides a wiping action (when disconnected) to clean terminals from oxidation build up.
  • Double terminal screws on "All" amperage devices.
  • Internal "Swing Away" Strain Relief is inside device.
  • Ground "First to mate – Last to break" no shock safety.
  • Arc flash protection if disconnected under-load all pins Male & Female are always completely covered.
  • Chamfered funnel entry terminals guide and captures all wire strands.
  • Neoprene "Onion Ring" cable sealing bushing – range taking seal.
  • Economical back shell (cable sleeve). Easy identification for assembler to determine wire size.
  • Back shell comes with Electro Zinc Plated Steel screws – corrosive resistant.
  • Spring loaded flip cover. Protects against splashing water from any direction.

Product Specifications

  • HEIGHT INCHES6.73
  • CERTIFICATIONS UL Listed
  • BRANDF. Walther Electric
  • PHASE3
  • FROM AWG/TYPE12 / S
  • TO AWG/TYPE8 / S
  • ENCLOSURE MATERIALHigh Impact Thermoplastic Housing
  • ENVIRONMENTAL RATINGIP44
  • WIDTH INCHES3.86
  • VOLTAGE400/480
  • AMPERAGE30/32
  • COLORRed
  • POLES AND WIRES3 Pole, 5 Wire
  • MANUFACTURERS PART NUMBER332
  • TYPESingle
