Floor Crane with Telescopic Boom EHN-60-T 6000 Lb. Capacity

Use as a Boom Lift or Platform Lift Rugged yet versatile welded steel crane is perfect for positioning loads where they are needed. Convenient hand crank winch raises loads in two unique ways:Overhead Lifting Boom with 22 ½" reach raises loads from 0" to 81"H using safety hook or use as aPlatform Lift by simply attaching 20 ½"W x 20"D platform to hook for 16" to 71"H lift range. Unit can be easily disassembled for storage or transport. Twin push handles with safety grips offer easy steering and rolls smoothly on four 8" x 2" phenolic swivel casters - (2) with brakes, and (2) without ...

REVERSED BOOM FLOOR CRANE Reversed boom design eliminates front leg interference, allowing crane to get into, under and over obstacles in tight spaces. Provides safe, easy lifting in production areas and warehouse with simple hand operated hydraulic lift. Integral overload relief valve. Needle valve regulates lowering speed. Alloy steel safety swivel hook and counterweight are included. Highly maneuverable with a rear mounted tow handle and roller bearing phenolic wheels. Factory tested to 150% of capacity and exceeds ASME PALD-12 and ANSI Z-535 standards. 2 Year Limited Warranty. ...

Mounts easily in Standard Class III or greater 2" Hitch Receivers. This hitch-mounted truck Jib Crane requires no modifications to the receiver or the truck. Crane may be adjusted and leveled for best use in all conditions. Offset upright design does not restrict tailgate use while installed. Manual hand brake winch with 25' cable and lifting hook is included. Hitch crane safely keeps the load centered over the truck bed while rotating. Rugged, welded steel construction with powder-coat black finish. Maximum uniform lifting capacity is 600 pounds. Crane may be installed on either side of ...

The short boom length of this crane is perfect for use in tight, restricted space areas. Each crane includes integral fork pockets, safety restraint and 2 hoisting hooks (one swivel, one rigid). Heavy duty robotically welded steel construction features a durable chip-resistant enamel finish. Maximum Load on a Single Hook: At Inner Hook = 4000 lbs. At Outer Hook = 2750 lbs. ** "S" Dimension is the dimension from the center to center of the fork tine sleeves. NOTE: OSHA requires contacting the manufacturer of your truck for written approval for the use of any fork truck attachments.

The fully powered electric floor crane has an easy and quick operation. The unit raises and lowers loads with a push of a button. It can maneuver loads in warehouses and trailers. The heavy duty rigid hook with safety latch provides long service. The high-torque DC drive and lift motors handle heavy-duty jobs. Floor crane includes integral battery charger, battery level gauge, and emergency battery disconnect. The truck rolls smoothly on poly-on-steel, steer and load wheels. The ergonomic handle features an easy to operate throttle with infinite adjustment of forward and reverse speeds, ...
