NACHI Super Precision Bearing BNH013TU/GLP4, Universal Ground, Single, 65MM Bore, 100MM OD
NACHI Features
NACHI Features
- Small Ball Diameter & Optimum Internal Design generate higher speed and lower heat generation
- Interchangeable with 7000 series with identical boundary dimensions
- Two bearings are used in a duplex pair to provide a high degree of rigidity in both radial & axial directions
- Meets the needs of machine tool manufacturers for precision bearings (15° contact angle, P4) that can operate at lowest possible temperature for wide range of speeds & operating loads
- These Universal Flush Ground Bearings can be mounted in DB, DF or DT
- BRAND Nachi
- BEARING STYLE Single
- BORE DIAMETER MILLIMETERS 65
- OUTER DIAMETER MILLIMETERS 100
- WIDTH MILLIMETERS 18
- DYNAMIC LOAD RATING (N) 21500
- STATIC LOAD RATING (N) 23400
- CAGE TYPE Phenolic
- MANUFACTURERS PART NUMBER BNH013TU/GLP4
- PRELOAD Light
- TOLERANCE P4 (ABEC7)
- SERIES 7000
- CONTACT ANGLE 15
- MAX SPEED / OIL (RPM) 23000
