NACHI Super Precision Bearing BNH016TU/GLP4, Universal Ground, Single, 80MM Bore, 125MM OD
NACHI Features
NACHI Features
- Small Ball Diameter & Optimum Internal Design generate higher speed and lower heat generation
- Interchangeable with 7000 series with identical boundary dimensions
- Two bearings are used in a duplex pair to provide a high degree of rigidity in both radial & axial directions
- Meets the needs of machine tool manufacturers for precision bearings (15° contact angle, P4) that can operate at lowest possible temperature for wide range of speeds & operating loads
- These Universal Flush Ground Bearings can be mounted in DB, DF or DT
- BRAND Nachi
- BEARING STYLE Single
- BORE DIAMETER MILLIMETERS 80
- OUTER DIAMETER MILLIMETERS 125
- WIDTH MILLIMETERS 22
- DYNAMIC LOAD RATING (N) 35000
- STATIC LOAD RATING (N) 39000
- CAGE TYPE Phenolic
- MANUFACTURERS PART NUMBER BNH016TU/GLP4
- TOLERANCE P4 (ABEC7)
- PRELOAD Light
- SERIES 7000
- CONTACT ANGLE 15
- MAX SPEED / OIL (RPM) 18500
Customer Review
Product Q & A
There are no questions for this product.
NACHI Super Precision Bearing BNH016TU/GLP4, Universal Ground, Single, 80MM Bore, 125MM OD
$502.0
