Buyers Wetline Kit Option, UCCS1ACM, Console Shift System Kit

Upright reservoir Frame bracket kit with fasteners Reservoir isolation package 46 GPM cast iron pump/valve combination with bracket 6-foot internally reinforced 1-1/4" suction hose Two 1-1/4" barbed adaptor fittings Two 1-1/4" S.S. hose clamps One 1" high pressure swivel adaptor One 1" wing type high pressure quick detach coupling One 6-foot long 1" high pressure hose

10-foot 1-1/4" dia. return line hose Four 1-1/4" barbed adapters Four 1-1/4" hose clamps Return line filter with bypass and two 25 micron spin on elements Pump/valve bypass sleeve

Single or Dual flow regulator with built-in on-off control plus system relief and pressure compensated Built-in differential style relief valve and on-off valve in a single compact body Permits easy installation with min. plumbing Detent hand knob for each flow control Easy to adjust flow, 11 positive positions Aluminum body All ports are 3/4" NPT, except 1/2" NPT spinner port Relief cartridge std. setting 1500 PSI (105 bar)

Operates Live Floor Trailer Kit Includes: 37 gallon reservoir Dowelled pump w/built in relief Ball valve, wing couplers, hose, fittings, clamps and adaptors Tank mounted filter 50 GPM This system is designed for optimum speed and longevity

Side mount reservoir Reservoir bracket kit with fasteners 46 GPM cast iron pump/valve combination with bracket 6-foot of internally reinforced 1-1/4" suction hose Two 1-1/4" barbed adaptor fittings One 1-1/2" x 1-1/4" reducing bushing Two 1-1/4" S.S. hose clamps One 1" high pressure swivel adaptor One 1" wing type high pressure quick detach coupler One 6-foot long 1" high pressure hose
