IGUS EBLI-04R 4" Left-Hand Female Rod-End Bearing

iglide® clip bearings are designed specifically for putting shafts through sheet metal plates. For this reason, the bearings have flanges located on both ends. The bearings are secured in the sheet metal plate on both sides after installation. The clip bearings are slit at an angle, so installation of the bearings is possible from one side. After installation, the bearing opens and forms a lining for the bore hole in the metal plate. The shaft prevents the clip bearing from detaching from the housing. Even during axial movement, the bearing remains secured in the housing. In addition, the ...

Special Properties: Closed, anodized aluminum housing Liner JUI-01 made from iglide® J contained according to standard tolerances Can be fitted with T500 liner material for temperatures up to 356°F Low clearance liners optional

The DryLin® N series offers extremely low profiles in several widths, and is therefore ideal in tight space constraints. Like all DryLin® products the carriages are designed to glide smoothly on anodized aluminum rails without the need for messy lubricants. They are also available in preloaded versions for reduced running clearance. DryLin® N is a particularly low-cost alternative to miniature ball bearing systems, and is more precise and economical when compared to many custom-machined or simple plastic parts. Small mounting height and width Maintenance-free and self-lubricating High ...

Special Features: The iglide® Clip2 bearing is a thin-walled bearing made from the iglide® M250 material and which has a beveled edge for extremely simple installations. The diagonal slit helps to compensate for poor housing bore tolerance as well as temperature and humidity changes. Split version of the iglide® M250 bearing Easy assembly by hand Compensation for heat expansion Suitable for ambient temperatures with high humidity Lightweight Very economical Inch and metric sizes available from stock Low bearing clearance, very accurate Maintenance-free and predictable service life

Features: Low profile and compact High torsional rigidity Fully supported Hard-anodized rail 5 sizes Zinc die-cast or anodized aluminum end blocks (SLW-0630 = polymer) Stainless steel version SLW-1040-ES available Diagram Dimension L2: 17 Screw Diameter: 10 mm Diagram Dimension Kt: 6-3/8 Dimension Al: 69 Diagram Dimension Kq: 4-3/8 Diagram Dimension Sk: 9-1/2 Diagram Dimension Tg: M8 Max Axial Load: 157 lbs. Dimension E3: 56 Diagram Dimension Ha: 14-1/2 Dimension E2: 60 Diagram Dimension Lt: 22 Diagram Dimension Sg: M6 Diagram Dimension Tk: 11 Lead: 2 mm Diagram Dimension Ts: 6-13/16
