Baldor-Reliance Motor L1408T, 3HP, 1725RPM, 1PH, 60HZ, 184T, 3634LC, OPEN, F1

General Purpose, Capacitor Start-Inductor Run Motor: 3HP, 1740 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 184 Frame, Rigid Mount, 115/208-230V, 1PH, 60HZ, Name Plate Amps 33.6/16.8, Continuous duty, 1.0 Service Factor, No thermal protection, Efficiency: 77, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length 2-1/4, Shaft Diameter 1 1/8. Totally enclosed fan cooled (TEFC) enclosure has no vent openings, and is tightly enclosed to prevent the free exchange of air, but is not airtight. An external fan is an integral part of the motor and provides cooling by ...

Baldor-Reliance Motor, ... Features: Heavy guage steel frames Ball bearings Base is seam welded to frame Snap Action starting switch for reliability Typical Applications: General purpose including compressors, pumps, fans, farm equipment, conveyors, material handling equipment, machine tools, etc.

In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired. Features Ball bearing design 1-1/2 horsepower ratings are rated at 14 amps or less on 115 volts Manual thermal overload located in the conduit box UL and CSA recognized component approval 200°C copper windings Application(s) ...

Baldor-Reliance Motor, ... Features: Heavy gauge steel frames Ball bearings ISR® (Inverter Spike Resistant)copper windings Low-loss electrical grade laminations steel Three year warranty Typical Applications: Typical applications include operations where continuous or frequent duty is required. Super-E single phase motors are designed to conserve energy over extended time periods.

Baldor-Reliance Motor, ... Features: Heavy gauge steel frames Ball bearings ISR® (Inverter Spike Resistant)copper windings Low-loss electrical grade laminations steel Three year warranty Typical Applications: Typical applications include operations where continuous or frequent duty is required. Super-E single phase motors are designed to conserve energy over extended time periods.
