The California Air Tools EZ-1 Automatic Drain Valve has been designed to eliminate manually draining your air compressor air tank. The manually set timer allows you to set the time for both the frequency and duration of the draining process. The sturdy large steel cabinet on caster wheels makes it easier to move and reduces the noise level. The interior of the cabinet is lined with acoustic sound proofing foam insulation to reduce the air compressor's noise and vibration. The two latching door handles allows for easy access to the air compressor. The two exhaust fans are designed to remove the air from the cabinet for a cooler running air compressor. This air compressor is ideal for anyone working inside (office, shop, store, warehouse or home) where noise is a major issue. Designed for the person looking for Power, 98% Dry Air with Low Dew Point Air Flow and Less Service with at Least 50% Less Noise! Ideal for Dental, Milling, Bio-Tech, Surgical, Manufacturing Clean Rooms, Restaurant and General Engineering Applications.
Features
- Ultra Quiet - Only 58 decibels
- Oil-Free Pump (Class 1) – Cleaner air for better tool operation, Less maintenance and Costs
- Two pressure control gauges
- Two Female Industrial "Push to Connect" quick connector air ports (1/4" NPT)
- 0.01 Micron Prefilter
- 5.0 Micron (Class 2) Air Filter & Regulator
- Condor Pressure Switch
- Thermal Overload Protector
- 125 PSI Maximum Pressure
- 110 Volts / 60 Hertz / Single Phase
- Low Amp Draw - 14 Amps
- Time to fill tank from empty to full - 120 Seconds
- Recovery time from 95 PSI to 125 PSI - 25 Seconds
- Duty Cycle - 70/30
- Less heat which dissipates more efficiently
- Solid Steel Cabinet, Insulated
- L (26") x W (30") x H (39.5")
- 221 pounds
- Air Dryer Cartridge uses a High-Temperature Molecular Sieve Desiccant
- Easy to remove (spin off) and replace every 4000 hours or 2 years
- Aftercooler (condenser)
- PDP performance range (-20°F. to -51°F.)
- Air Quality: ISO 8573 - Class 2.3.1
- EZ-1-2321 Auto Drain Valve Factory Installed
- 1 Year Limited Warranty
- Comes complete (2) Air Filters
- Commercial Use
- Non-ASME Air Tank
- Assembled in Mexico and USA with global components
