Dynamic DE2-12-SAE, High Pressure Ball Valve 1 1/16-12" SAE Thread 5800 PSI

All valves are: 12 VOLT, 2.4 Amps Rated to 11 GPM (NON PROPORTIONAL) All ports are #8 SAE Straight thread Valve rated to 4300 PSI with higher pressure main relief (non standard) Main relief 1300-3000 PSI; Set at 2150 PSI Port relief angle 1900-4300 PSI;Set at 2150 PSI Port relief dump 400-1900 PSI;Set at 600 PSI All valves have cylinder spools unless specified as motor.

Typical Application: Grease,instrumental and most hydraulic systems Pressure: Up to 3000 PSI depending on pipe size. Sealing Method: 1-piece tapered pipe,dryseal (NPTF) Vibration Rating: Fair resistance Material: Carbon steel - AISI/ SAE 12L14 Advantage: Dryseal pipe threads(NPTF), zinc plate, compact size, broadselection of styles and sizes. Conformance: Meets SAE specifications

Buyers Connector Hex Nipple, H3069/16, 1" X 1" NPT Male To Male Typical Application: Grease,instrumental and most hydraulic systems Pressure: Up to 3000 PSI depending on pipe size. Sealing Method: 1-piece tapered pipe,dryseal (NPTF) Vibration Rating: Fair resistance Material: Carbon steel - AISI/ SAE 12L14 Advantage: Dryseal pipe threads(NPTF), zinc plate, compact size, broadselection of styles and sizes. Conformance: Meets SAE specifications

Pilot operated Also available 1/2" NPTF Working pressure 3625 PSI / 250 BAR Maximum pressure 4422 PSI / 315 BAR Cracking pressure 72.5 PSI / 5 BAR Used to convert latch pin plow applications to power angle plow

Series 232 is a series of robust screw-to-connect couplings. The standard version is equipped with a ball type valve, but it is also available with poppet valve for considerably higher flow performance. These hydraulic couplings are compliant with ISO 14540 to ensure complete interchangeability with other brands following the same standard. High flow rate capacity, high quality and ability to withstand harsh conditions, make them an ideal fit for many different applications. Flow capacity is measured at 50 PSI pressure drop. Check with an authorized CEJN distributor for availability and ...
