Hubbell Swing Boom W/ Floor Or Bench Mounted Support, 36"W x 50"H, Beige

Abell-Howe® Foundationless Base Mounted Light Duty Jib Crane 4L0027 1000 Lb. Capacity The Abell-Howe J-904L Series was developed to be a foundationless jib for light duty industrial applications requiring only 6" concrete depth. Requires epoxy anchor bolts (HILTI RE-500 adhesive anchoring system required 4 1/2" embedment) Jib provides 360 degree rotation on a tapered roller bearing providing full capacity vertical and radial thrust loading. Concrete floor mush be at least 6" thick and contain wire mesh reinforcement, in minimum soil pressure of 2,500 psf and minimum concrete compressive ...

Contrx tight wire kit keeps hoist power cord from drooping. Includes an S-hook with 1/8" cable, a cable clamp, eyebolt and nut-lock washer.

FESTOONED BOOM ELECTRIFICATION FOR Abell-Howe® LIGHT DUTY STYLE A FLOOR CRANES For 360 Degree Jib Rotation. Looped wire system provides electric power to hoist as it moves along the jib boom. Kit includes: 1/8" x 20'L tension wire and support brackets, one trolley for every five feet of boom. Fits Light Duty Style A Cranes only.

Jib Kit-Heavy Duty Floor Mounted, 50 Lb. Cap. 6 Ft. Fixed Boom on 7' Column Jib kits feature heavy duty I-beam booms or C-rail booms Vertical columns include pre-drilled, gusseted mounting bases. 50 lb. Capacity kits are available with either fixed or swing booms up to 18 ft. (5.4m) long .Columns available to 10 ft. (3.0m) high. Booms on 150 lb. and 300 lb. capacity jibs are mounted to top of column with tapered bearing and heavy-duty rollers allowing full 360 swing. Vertical columns for 50lb. capacity jibs also available separately.

The WS50 Rail 6' is made to support loads up to 50 Lbs. Can be utilized as a wall or column mounted tool rail; or function in pairs to create two fixed booms as support for a horizontal tool rail. (Cross rail and hangers not included). End stop and end cap included. The rail features an industrial standard beige polyester finish. The *8 ft. (2.4m), 10 ft (0.3m), and 18 ft. (5.4m) booms include a ladder style reinforcing superstructure. Trolley extra. Features include fixed or 180° Swinging WS50 Booms.
