JET® PT Series Heavy Duty Manual Trolley 252060 22,000 Lb. Cap.

JET® PT Series Heavy Duty Manual Trolley 252060 22,000 Lb. Cap.

Item #: WBB1532141

Not Yet Rated

Enter zip code for delivery date estimate

Shipping to 10465 change

$1,954.00 up to 38% OFF

Price: $1,220.99

$203.50 / month suggested monthly payments with 6 mo. special financing on the purchase of $1,220.99 or save 5% on purchase.

Quantity

Customers Also Viewed

JET® PT Series Heavy Duty Manual Trolley, 22,000 Lbs. Cap.

JET® PT Series heavy duty manual trolleys are available in capacities from 1/2 ton to 10 Tons. Built with heavy gauge steel for increased durability, the large steel wheels and thicker bearings provide smooth movement on a variety of beams. The built in bumper guards increase user safety and extend the life of the trolley. Each JET® Manual Trolley conforms to OSHA regulations, and ANSI / ASME standards

Durability
  • Welded heavy gauge steel frame and powder coat finish provide maximum durability and protection
  • Hardened large steel wheels and thicker double sealed lubricated ball bearings provide smooth movement
  • Built-in bumper guards on the side plates increase safety and extend trolley life
  • Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
Standards
  • Complies with OSHA Regulations, ANSI / ASME B30.11 and B30.17 standards
  • Certification- Load tested to 125% of capacity with certificate


Product Specifications

  • LENGTH INCHES20
  • WIDTH INCHES11-1/2
  • HEIGHT INCHES15-1/2
  • CAPACITY LBS22000
  • COLOR FINISHWhite
  • APPROVAL/REGULATIONSOSHA Regulations, ANSI / ASME B30.11 and B30.17
  • ASSEMBLYAssembled
  • BEAM WIDTH INCHES4-3/4 to 8
  • BRANDJET®
  • CONSTRUCTIONSteel
  • HEAD ROOM INCHES11-5/8
  • I-BEAM HEIGHT INCHES5 to 19
  • LIMITED WARRANTY2 Years
  • MANUFACTURERS PART NUMBER252060
  • MAX. FLANGE THICKNESS INCHES8
  • MINIMUM RADIUS CURVE INCHES67
  • OPERATIONManual
  • REFERENCE #10-PT
  • SERIESPT
  • WEIGHT LBS210.25
  • UPC662755223334
  • PACKAGE QUANTITY1
