A standard rule is that the table top cannot be 2 feet wider than the base frame. An example of this is that a 48" wide base table can have up to a maximum top width of 72". However, if this was a double wide 48" wide base, the top could be 12 feet wide.
The other benefits of double wide base tables are increased capacity and increased edge loading.
Features:
- Internally mounted 1.5 HP 115/230V-I-60 or 230/460-3-60 intermittent duty TENV super torque motor
- 115V operating control voltage
- NEMA constant pressure. Magnet backed up-down push button control station with 10' straight or coiled cord
- All controller components meet UL and/or CSA specifications
- Cylinders with internal stops
- 10' power cord (connector not included)
- Integral safety restraint maintenance bars
- S.A.E. hoses and fittings
- NEMA - 1 prewired controls and electrical connectors. Control box contains contactor, control transformer, thermal overload and fuse
- Hard, chrome plated, polished shafting hydraulic cylinder piston rods
- Surfaces degreased, descaled and finished with Safety Yellow and Blue enamel
- Smooth steel top with yellow and black safety strips
- Internal gear pump with check valve, relief valve, solenoid valve
- Includes hydraulic oil and filter
