Furnished with 3/8-16 or 1/2-13 tapped holes or studs to accommodate large or small holes in the machinery leg. Neoprene resists oil, oxygen and ozone. Upper plate provides uniform mounting loading. May be bolted directly without leveling for economy. Without glide cup, friction keeps equipment in place. Max Load 150 LBS. 2-1/4"L x 2-1/4"W x 7/8"H Overall Dimensions.
Share
Spec Sheet
R-5 Neoprene Leveling Mount - Green
Write a Review
|
Questions & Answers (0)
Product Description
PRICE
$19.00
1
1
Bulk Pricing
Quantity
Pricing
Buy 1 unit - 9 units
19.00
Buy 10+ units
18.25Save $0.75 (4%)
Ships in 4 Business Days
Add or Change Zip Code(s)
Easy online or call-in returns. Read return policy
Specifications
Weights & Dimensions
| Length | 2.25 in |
| Width | 2.25 in |
| Height | 0.88 in |
| Weight Capacity | 400 lbs |
| Load Capacity Range | 100 - 500 lbs |
| Mount Hole Diameter | 0.50 in |
| Unit of Measurement | Inch (Imperial) |
| Base Diameter | 2.25 in |
Product Details
| Type | Tapped Mount |
| Color | Green |
| Country of Origin | Import |
| Material | Neoprene/Steel |
| Package Quantity | 1 |
| Manufacturers Part Number | R-5-150 GREEN |
| Brand | Mason Industries |
