Guardian Equipment Safety Station w/ Eye & Face Wash, Shower Head & Bowl
Write a Review
|
Questions & Answers (0)
Product Description
Application: Combination eye/face wash and shower safety station. Eye/face wash features a stainless steel bowl with two large FS-Plus spray-type outlet heads that deliver a flood of water for rinsing eyes and face.
Shower Head: 10" diameter orange ABS plastic with 20 GPM flow control.
Shower Valve: 1" IPS chrome plated brass stay-open ball valve. Valve is US-made with chrome plated brass ball and PTFE seals. Furnished with stainless steel actuating arm and 29" stainless steel pull rod.
Spray Head Assembly: Two FS-Plus spray heads. Each head has a "flip top" dust cover, internal flow control and filter to remove impurities from water flow.
Eye/Face Wash Bowl: 11-1/8" diameter stainless steel.
Eye/Face Wash Valve: 1/2" IPS chrome plated brass stay-open ball valve. Valve is US-made with chrome plated brass ball and PTFE seals.
Pipe And Fittings: Schedule 40 galvanized steel. Furnished with orange polyethylene pipe covers for high visibility and corrosion resistance.
Supply: 1-1/4" NPT female top or side inlet.
Waste: 1-1/4" NPT female outlet. Outlet can be positioned at either 9-1/4" or 19-5/8" above finished floor by reversing lower pipe nipples.
Sign: ANSI-compliant identification sign.
Quality Assurance: Valve and spray head assemblies are factory assembled and water tested prior to shipment.
Shower Head: 10" diameter orange ABS plastic with 20 GPM flow control.
Shower Valve: 1" IPS chrome plated brass stay-open ball valve. Valve is US-made with chrome plated brass ball and PTFE seals. Furnished with stainless steel actuating arm and 29" stainless steel pull rod.
Spray Head Assembly: Two FS-Plus spray heads. Each head has a "flip top" dust cover, internal flow control and filter to remove impurities from water flow.
Eye/Face Wash Bowl: 11-1/8" diameter stainless steel.
Eye/Face Wash Valve: 1/2" IPS chrome plated brass stay-open ball valve. Valve is US-made with chrome plated brass ball and PTFE seals.
Pipe And Fittings: Schedule 40 galvanized steel. Furnished with orange polyethylene pipe covers for high visibility and corrosion resistance.
Supply: 1-1/4" NPT female top or side inlet.
Waste: 1-1/4" NPT female outlet. Outlet can be positioned at either 9-1/4" or 19-5/8" above finished floor by reversing lower pipe nipples.
Sign: ANSI-compliant identification sign.
Quality Assurance: Valve and spray head assemblies are factory assembled and water tested prior to shipment.
PRICE
$1,255.00
1
1
Ships in 5 Business Days
Add or Change Zip Code(s)
Easy online or call-in returns. Read return policy
Weights & Dimensions
| Length | 17 |
| Width | 41 in |
| Height | 33 in |
| Weight | 10 lbs |
| Bowl Diameter | 11-1/8 in |
| Inlet Size | 1-1/4 NPT Female in |
| Shower Head Diameter | 10 |
| Outlet Size | 1-1/4 NPT Female in |
Product Details
| Flow Rate | 20 gal/min |
| Mounting Location | Floor |
| Material | Galvanized Steel |
| Manufacturers Part Number | G1950 |
| Eyewash Flow Pressure | 30-80 psi |
| Eyewash Activation | Flag Handle |
| Bowl Color Family | Stainless |
| Brand | Guardian Equipment |
| Shower Flow Rate | 20 GPM |
| Eyewash Handle Material | Aluminium |
| Color | Orange |
| Eyewash Flow Rate | 6.4 gal/min |
| Shower Head Material | ABS Plastic |
| Pipe Material | Galvanized Steel |
| Number of Heads | 2 |
| Eye/Face Wash Activator | Flag Handle |
| Shower Head Color Family | Orange |
| Includes | Emergency Shower/Eyewash Sign, Inspection Tag |
| Valve Type | 1/2" IPS Open Ball Valve |
| Activation | Pull Rod |
| Bowl Material | Stainless Steel |
Warranty
| Warranty | 2 yr |
Compliance & Certifications
| ADA Compliant | No |
| ANSI Certification | Z358.1-2014 |
