Regulators

For optimal performance, Model 652 combines a filter, regulator and flat gauge in one product. The filter will remove any moisture or debris and the regulator provides a controlled and consistent air pressure. Thanks to its compact design, it is a good alternative in applications where space is limited. Model 652, piggyback, manages compressed air systems operating up to 16 bar (232 PSI) inlet pressure. The model features a polycarbonate bowl, easily visible level indicators, locking device and for extended lifetime, a flexible rolling diaphragm. Application: Virtually every industry, ...

MGAR series regulators boast excellent regulation and flow characteristics at an economical price. Available port sizes range from 1/8" NPT to 1" NPT. The push-to-lock knob assures the desired outlet pressure is maintained. Reverse flow is available with the MGARK option. Features: Body Material: Aluminum Type: Relieving / Press-to-lock adjustable knob Pressure Ratings: 7 to 130 PSI / 7 to 60 PSI (low pressure) Temperature Range: -4⁰ F to 158⁰ F All "in-stock" regulators ship the same day Includes: Gauge / Bracket / Nut / 2 Gauge Locations

5 Stage desiccant drying system. Provides -30 degree dew point. Includes 40 micron water removing filter, .01 micron coalescing filter, 1 gallon desiccant dryer, 3 micron filter/regulator and shut-off valve.

✓ Effectively removes water vapors & any liquid contaminants from airlines ✓ Compatible with many stationary air compressors ✓ Ideal for use in automotive & industrial paint applications Protect your air system by maintaining compressed air quality with the Arrow Pneumatics StageAir Desiccant Dryer. Compatible with any stationary single-stage, two-stage, rotary, scroll, or duplex compressor, this 5-stage desiccant drying system is designed to remove any residual liquid contaminants in an airline. This unit provides a -30° dew point and includes a ...

1/2" NPT high pressure regulator is the heavy duty relieving type and offers a stable downstream air pressure over a wide range of air flows with accurate control fast response time and minimal pressure drop. Offset gauge ports can also serve as two 1/4" supply lines. The aluminum die cast body comes with a balanced piston and molded rubber seat. Mas a maximum inlet pressure of 250 PSI and offers up to 100 SCFM.
