Features
- Recommended Breaker: 20 Amp
- Magnetic Starter
- Min-Max Blade Width: 1/8" – 1-1/4"
- Resaw Capacity: 16"
- Throat: 18-7/32"
- Blade Length: 145"
- Disc-Brake With Micro Switch
- 110V Outlet On Back For Light
- Window For Tension
- Window For Tracking
- Magnetic Blade Tension Guide
- Worm Gear & Pinion Upper Guide
- 10 Point Laguna Ceramic Guides
- Mechanical Variable Speed Drive
- Low Blade Speed: 100-290 FPM
- High Speed Blade: 1200-3500 FPM
- Anodized Insert With Micro Adjustment
- Dynamically Balanced Cast Iron Wheels
- Urethane Single Piece Snap-On Tire
- Cast Table Size: 20" x 26"
- Table Tilt: 6°, +45°
- Quick-Release Tension
- Hi/Low Anodized Aluminum Fence: 22-3/4" x 7-1/4" x 11/16"
- Table Height: 38"
- Dust Ports: 4" x 2
- Overall Height: 77-3/4"
- Dimensions (Base): 27" x 20"
- Dimensions (Overall): 38" x 36"
- Dimensions (Box): 82" x 34" x 36"
- Weight: 480 lbs.
- Foot Operated
- 360° Omni-Directional
- Rubber-Coated Wheels
- Adjustable Rubber Pads
- Oilite Bronze Bushing Allows For Less Friction & Longer Life
- Easy Install With No Drilling Required
- Pedal Raises & Lowers Front Wheel
- Wheels Mounted Outside Frame To Maximize Stability
- Swivels 220°
- 12 Volt/50 Watt
- Tilts Vertically 320°
- Built-In Transformer
- Independent On/Off
- Ribbed Aluminum Case
- Halogen Hi-Intensity Light
- Bright, Glare-Free Flood Light
- Designed for Even Light Distribution
- Reinforced Glass, Dustproof Design
- Top and Side Cabinet Mounting Position
