2 In. Stainless Steel Gate Valve - 200 PSI

10" T-303 OS & Y Cast Iron Gate Valve Features: Outside-screw-and-yoke stem design gives visual reference to disc wedge position and is more durable than non-rising stem designs, as the stem threads are external and aren't exposed to the media flow Class 125/150 flange-type end connections IBBM design: Iron-body-bronze-mount, with bronze seat and wedge sealing rings Solid wedge assures a positive drip-tight closure Durable cast iron construction resists pipeline stresses and distortion All external surfaces are primed and dual-coat painted for corrosion resistance Full-flow waterways ...

5" T-301 Cast Iron Non-Rising Stem Valve Features: Non-rising stem design is ideal for confined installations Class 125/150 flange-type end connections IBBM design: Iron-body-bronze-mount, with bronze seat and wedge sealing rings Solid wedge assures a positive drip-tight closure Durable cast iron construction resists pipeline stresses and distortion All external surfaces are primed and dual-coat painted for corrosion resistance Full-flow waterways minimize pressure drop Working Pressure, Non-Shock (PSI): Cold working pressure (CWP): 200 psi, Saturated steam (WSP): 125 psi to 450°F In ...

2 In. Stainless Steel Flanged Full Port Ball Valve - 2 Piece - Direct Mount - 300 PSI Ball valves use a spherical disc to control the flow between pipes, tubes, or hoses. Flow is allowed when the hole that pierces the ball-shaped disc is in line with the inlet and outlet of the valve. Flow is blocked when the ball is horizontally swiveled 90 degrees, so that the hole of the ball is perpendicular to the opening of the valve. Ball valves can be referred to as full port or reduced port (also known as regular or standard port) depending on the inner diameter of the valve. A ball valve is full ...

12" T-301 Cast Iron Non-Rising Stem Valve Features: Non-rising stem design is ideal for confined installations Class 125/150 flange-type end connections IBBM design: Iron-body-bronze-mount, with bronze seat and wedge sealing rings Solid wedge assures a positive drip-tight closure Durable cast iron construction resists pipeline stresses and distortion All external surfaces are primed and dual-coat painted for corrosion resistance Full-flow waterways minimize pressure drop Working Pressure, Non-Shock (PSI): Cold working pressure (CWP): 200 psi, Saturated steam (WSP): 125 psi to 450°F ...

The 6 inch non-rising stem resilient wedge flanged gate valve is designed for use in irrigation and water distribution services. It features an epoxy coated cast iron body with ANSI B16.1 flanged connections, resilient wedge disc, cast iron bonnet, bronze non-rising stem and is operated by a cast iron handwheel. The resilient wedge disc design offers both positive seating and resistance against high differential pressure. The maximum pressure rating is 200 psi (13.8 bar) CWP.
