Standard Equipment:
- Mitsubishi saw control
- Variable frequency drive
- Overfeed protection
- Work height sensor
- Discharge chute
- Pulley-driven band brush
- Flood coolant
- Tool kit
- Complimentary DoALL cutting fluids package
- One (1) DoALL bi-metal saw blade
- Instruction and parts manuals on CD or USB data stick
- Cutting capacity for round tube: 11.75" (300mm)
- Cutting capacity for rectangle: 11.75 x 12.5" (300x320mm)
- Cutting capacity for round solid: 7" (180mm)
- Index Single Stroke Min-Max: 0.12-19.7" (3-500mm)
- Auto Index Multiple Stroke Max: 394" (9999mm)
- Nesting Capacity Min to Max: 7.9" x 0.4" (200x10mm) up to 9 x 4.75" (230x120mm)
- Miter cutting: 0° - 60° right
- Miter cutting capacity for tube at 45° - Right: Round: 11.75" (300mm), Rectangle: 11.75 x 9.75" (300x250mm)
- Miter cutting capacity for solid at 45° - Right: Round: 4-1/4" (110mm)
- Miter cutting capacity for tube at 60° - Right: Round: 7.75" (200mm), Rectangle: 7.75 x 7.75" (200x200mm)
- Miter cutting capacity for solid at 60° - Right: Round: 3-1/8" (80mm)
- Min and max nesting capacity at 90°: 0.12" (3mm) to 12.5 x 6.25" (320x160mm)
- Remnant length drop: Width: 1.2" (30mm)
- Band saw blade dimensions: Width: 1 x 0.035" (27x0.9mm), Length: 144" (3660mm)
- Band speed: 65-328 fpm (20-100mpm)
- Band drive motor: 3 HP (2.4 kW)
- Hydraulic pump: 0.07 HP (0.05 kW)
- Coolant pump: 0.6 HP (0.44 kW)
- Coolant capacity: 5-1/4 Gal. (20 lit)
- Material pass line height: 31-1/2" (800mm)
- Machine weight: 1764 lbs (800 kg)
- Floor space requirements W x L X H: 91 x 90 x 60" (2309x2276x1503mm)
- Machine Voltages Available: 460vac, 3-Phase, 60hz, Wye configuration required
