Weights & Dimensions
| Weight | 29 lbs |
| Opposite End Bearing Size | 6203 |
| Dimension C | 16.45 in |
Product Details
| Power Factor | 55 |
| Drive End Flange | Standard |
| KVA Code | J |
| Motor RPM 60 Hertz | 1140 rpm |
| Mounting Location | Rigid |
| Phase | 3 |
| Manufacturers Part Number | BM3539 |
| Enclosure | TEFC |
| Brake Rating | 6 |
| Service Factor | 1.25 |
| Bearing Drive End | 6203 |
| Brand | Baldor-Reliance |
| RPM | 1140 rpm |
| Insulation Class | B |
| Horsepower | 1/2 HP |
| Frame | 56 |
| Hertz | 60 Hz |
| Design Code | B |
| Amps @ 208V | 2.7 A |
| Enclosure Type | Totally Enclosed |
| Voltage | 230/460 V |
| Full Load Efficiency | 72 |
| Full Load Amps | 2.4/1.2 FLA |
| Poles | 6 |
| Ambient Temperature | 40 °C |
| RPM Range | 1101-1200 rpm |
