Transforming Technologies Calibration Unit For PGT 120

The adjustable WB2580 dual wire fabric wrist strap set features two 180 degree conductive paths around the wrist, providing maximum skin contact. The band is standard with two 4mm male snaps and is used with dual wire resistance based constant monitors. Dual wire wrist straps provide ground redundancy. When used with dual wire resistance monitors, the WB2580 wrist strap sets continuously verify resistance to ground. The WB0025 wrist strap is constructed with a stainless steel back plates, nylon molding and a premium elastic yarn that provides excellent fit for comfort and long life. ...

The Transforming Technologies CS1090 ESD Universal Snap Kit includes everything needed to field-install a stud or socket on all soft materials up to 0.375" thick. The kit includes both a 10 mm stud, 10 mm socket, threaded backing washer, conical nut, long screw, and short screw. Screws are 6-32 Flat Head Phillips machine screws; one 0.25" long and one 0.375" long. To install, punch a hole through the mat with the screw driver or knife and screw on the socket or stud, whichever is preferred. All that is needed is a Phillips screwdriver. Instructions: Determine the position of the grounding ...

The Transforming Technologies Classic Straight Plug Coil Cord Series has 2.5 mm polyurethane coil insulation that offers excellent coil memory. A swivel type banana jack increases coil life and prevents cord tangles. The Classic Series works in combination with most standard 7mm snap wristbands. Cords come in 6′ and is also available in 12′ lengths. Meets or exceeds requirements of ANSI ESD-S20.20 and ESDA Standard 1.1-2006. Benefits & Features of the Transforming Technologies Classic Straight Plug Coil Cord:: Resistor: 1 meg ohm standard Flex Life: >50,000 flexes Color: Black Banana: ...

The CP2524 low profile ground cords are highly durable and reliable ground cords. Equipped with two standard banana jacks, the CP2524 grounds up to two operators at the same time. The low profile, molded head has built-in 10mm female snap for a secure worksurface attachment. A 15′ black ground cord terminate with a standard 1/8" (#10) ring terminal for a solid connection to ground. Also available with a 8mm ring terminal. Meets or exceeds requirements of ANSI ESD-S20.20. The Transforming Technologies CP2524 Specifications: Product Type: 15 feet Common Ground Cord with 10 mm male snap Two ...

What makes the PDT800M Combo Wrist Strap and Footwear Testing Station unique is the proactive Near-Fail Indicator that alerts the user that the ESD grounding device under test (wrist strap or heel grounder) is nearing failure levels and should be changed soon if not right away. The results are visible with the digital screen on the tester's face. This helps prevents a worn device "passing" a test and failing in the field. This tester fully supports the Compliance Verification Plan requirements as stated in the ANSI ESD S20.20. Simultaneously and independently test both feet and a wrist ...
