Dynamic DFC-51 Full Range Pressure Compensating Variable Flow Control 3/4-16" SAE PORT

RPE is a heavy duty rotary type variable speed controller with on/off switch. Brushed aluminum switch plate and screws included.

These valves will start or stop a hydraulic cylinder or motor and vary speed over wide range. Once set, it maintains constant speed regardless of load variations. Excess flow is returned to tank or used to power another function. Rated for 3000 PSI

Priority flow dividers split the oil from a single inlet into two separate flows One is a controlled, adjustable flow which has priority on the oil entering the valve The other is a secondary flow based on oil in excess of that demanded by the priority flow Both flows may be used simultaneously at different pressures without affecting the priority flow rate External adjusting knob controls priority flow rate Load may be applied to either port without affecting priority flow rate

Single or Dual flow regulator with built-in on-off control plus system relief and pressure compensated Built-in differential style relief valve and on-off valve in a single compact body Permits easy installation with min. plumbing Detent hand knob for each flow control Easy to adjust flow, 11 positive positions Aluminum body All ports are 3/4" NPT, except 1/2" NPT spinner port Relief cartridge std. setting 1500 PSI (105 bar)

Single or Dual flow regulator with built-in on-off control plus system relief and pressure compensated Built-in differential style relief valve and on-off valve in a single compact body Permits easy installation with min. plumbing Detent hand knob for each flow control Easy to adjust flow, 11 positive positions Aluminum body All ports are 3/4" NPT, except 1/2" NPT spinner port Relief cartridge std. setting 1500 PSI (105 bar)
