Hoffman ED1PBXM, Push Button Encl, Dome Cover, 1Pb X 22.5Mm

These Sloped Front Pushbutton Enclosures are designed to hold 30.5-mm or 22.5-mm pushbuttons and switches where slanted control surfaces are desired. Features: 14 gauge steel Seams continuously welded and ground smooth Captivated cover screws thread into sealed wells Grounding nut in body of enclosure Bonding provision on cover Oil-resistant gasket Factory stamped 4-way pushbutton holes Enclosures 7.25 x 6.25 x 6.75 in. (184 x 159 x 171 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit immediate removal External mounting brackets

An economical solution for a broad range of electrical and terminal wiring applications that don't require a back panel, this enclosure features aesthetic, rounded corners and is available in flat and dome cover models for mounting flexibility. Features: Drawn 16 gauge steel (no welded seams or sharp corners) Cover screws Formed flanged cover Oil-resistant gasket External wall-mounting brackets Bonding provision on flat cover; grounding nut in body

Hoffman E30PBA, Push Button Encl, Sloped Front, 30Pb X 30.5Mm These Sloped Front Pushbutton Enclosures are designed to hold 30.5-mm or 22.5-mm pushbuttons and switches where slanted control surfaces are desired. Features: 14 gauge steel Seams continuously welded and ground smooth Captivated cover screws thread into sealed wells Grounding nut in body of enclosure Bonding provision on cover Oil-resistant gasket Factory stamped 4-way pushbutton holes Enclosures 7.25 x 6.25 x 6.75 in. (184 x 159 x 171 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit ...

Features Prohibits access to a switch or control Fits both 30.5mm and 22.5mm diameter switches Clear bases and cover allow visibility of nameplates and labels Horse-show shaped retrofit base allows use with raised nameplates and off-center installation to accommodate rotary switch knobs Accommodates buttons up to 50mm diameter and 45mm tall Includes one cover, one new install base and one retrofit base with double-faced adhesive tape Patent pending

Hoffman E20PBA, Push Button Encl, Sloped Front, 20Pb X 30.5Mm These Sloped Front Pushbutton Enclosures are designed to hold 30.5-mm or 22.5-mm pushbuttons and switches where slanted control surfaces are desired. Features: 14 gauge steel Seams continuously welded and ground smooth Captivated cover screws thread into sealed wells Grounding nut in body of enclosure Bonding provision on cover Oil-resistant gasket Factory stamped 4-way pushbutton holes Enclosures 7.25 x 6.25 x 6.75 in. (184 x 159 x 171 mm) and larger have internal detachable hinge to hold cover open during wiring, yet permit ...
