Check & Foot Valves

3/4" FNPT In-Line Brass Check Valve with Stainless Steel Poppet. The Model 400 uses a stainless steel poppet for a metal-to-metal seal without the use of an o-ring and is best suited for heavy industrial usage. Product is Made in the USA. Maximum working pressure 200 psi, Maximum temperature 300°F, Cracking pressure 1-2 lbs. Use with hot water, cold water, steam, oil, gas, compounds, chemicals. Not for air compressor use.

Watts 0792093 3/4" Dual Check Valve This 3/4 inch hose bibb vacuum breaker is designed specifically for wall and yard hydrants to prevent the reverse flow of polluted water from entering into the potable water supply due to backsiphonage. It consists of lead free body construction, stainless steel working parts, a rubber diaphragm and disc, and a draining stem. It permits manual draining for freezing conditions. The maximum pressure is 125 PSI (8.6 bar).

10" T-312 Ductile Iron Wafer Check Valve, Stainless Steel Disc Features: Dual spring-loaded discs assure quick, silent closure Elastomer seats create a positive seal against backflow Can be installed vertically or horizontally, in any orientation Durable ductile iron body is designed to install easily between Class 125/150 companion flanges The compact body design is lighter and requires less installation space as compared to traditional flanged swing check valves The split-disc, center-torsional spring design minimizes pressure drop Working Pressure, Non-Shock (PSI): Cold working ...

1/2" FNPT In-Line Nickel-Plated Brass Check Valve with Stainless Steel Poppet. The Model 2400 uses a stainless steel poppet for a metal-to-metal seal without the use of an o-ring. It also features a nickel-plated valve body inside and out, with all internal components of stainless steel. Product is Made in the USA. Maximum working pressure 200 psi, Maximum temperature 300°F, Cracking pressure 1-2 lbs. For use in food and beverage applications, steam, and biodiesel. Not for air compressor use.

Check valves are mechanical valves that permit gases and liquids to flow in only one direction, preventing flow from reversing. They are classified as one-way directional valves. Fluid/gas flow in the desired direction opens the valve, while backflow forces the valve closed
