Vibco Pneumatic Piston Vibrator - 50-2

Heavy Duty line of Silent Pneumatic Turbine Vibrators. High amplitude and force output. Built in muffler. Heavy duty ductile and cast iron construction. CCF used for permanent foot mount applications. 80 PSI max. operating pressure, 6000 VPM, 40 CFM, 2000 lbs. of force. Factory recommends filter-regulator for optimum life and performance.

50 series Pneumatic Piston Vibrator, Silent air cushioned style. Nominal 1" dia. piston. Three piece steel construction. 6500 vibrations per minute (VPM) @ 80 psi (max. operating pressure). 5 CFM. All piston style vibrators must have a Filter-Regulator and Lubricator for proper operation.

70-3/4S Silent Air Cushion End-tapped Pneumatic Piston Vibrator. 3/4" dia. piston (19 mm), 3/8-24 threaded mounting hole (also available with M10 x 1.5 metric thread). 80 PSI max operating pressure, 5100 VPM, 5 CFM. Also available with Exhaust Manifold, or as Impacting type. Lubricated air is mandatory for proper operation of all piston type vibrators.

Hobo Railcar Shaker. CCW wedge mount for portable applications to be used with Female Railcar Bracket. Lightweight aluminum construction, only 22 lbs., ideal for light duty and clean out applications. 80 PSI max operating pressure, 6000 VPM, 30 CFM, 2500 lbs of force. Factory recommended filter-regulator for optimum life & performance.

55 Series Silent air cushioned piston vibrators, one piece cast iron design, slotted mounting holes to accomodate a variety of competitive bolt pattern. 80 PSI max operating pressure. 6600 VPM, 5 CFM. Piston style vibrators must have filter regulator and lubricator for proper operation.
