Vibco Small Impact Electric Vibrator - SPR-80

V series are foot mount Ball style vibrators, designed for applications requiring medium amounts of vibration. Threaded exhaust port allows for porting air to remote location if necessary. 80 PSI max operating pressure, 16000 VPM, at 11 CFM of air, with 260 lbs of force. Ball style vibrators must have a filter regulator and lubricator for proper operation. Exhaust mufflers are available for quieter operation.

BIG BERTHA 12 Volt DC dump body vibrators are ideal for field or mobile applications, available in 12 & 24 DC, Factory set to 3500 lbs of force, 60 amps, 4000 RPM, special duty. Field adjustable force 1500 lbs to 3500 lbs. Mounting Kit (carbon steel mounting plate, bolts, and washers), & Wiring Kit (34 feet of #4 AWG cable, 20 feet #16MTW, 7 ring terminals, push button switch, solenoid, and circuit breaker) included for easy installation. Stainless Steel, Aluminum Mounting Plate and Channel Iron available.

Heavy Duty line of Silent Pneumatic Turbine Vibrators. High amplitude and force output. Built in muffler. Heavy duty ductile and cast iron construction. CCF used for permanent foot mount applications. 80 PSI max. operating pressure, 6000 VPM, 40 CFM, 2000 lbs. of force. Factory recommends filter-regulator for optimum life and performance.

VS series Silent Turbine Vibrator with built in muffler for High Temperature Applications, 350° F max. (180° C). Graphite Impregnated Bearings. 7200 VPM, 10.5 CFM, @ 80 PSI, with 500 lbs. of force. No lubrication required. Factory recommended filter regulator for optimum performance. Factory recommended filter regulator for optimum life and performance.

BV series are dual mount Ball style vibrators, designed for applications requiring medium amounts of vibration. Threaded exhaust port allows for porting air to remote location if necessary. 80 PSI max. operating pressure, 16000 VPM, at 11 CFM of air, with 260 lbs of force. Ball style vibrators must have a filter regulator and lubricator for proper operation. Exhaust mufflers are available for quieter operation.
