10 Ton Proto-Ease™ Pullers, PROTO 4234B

Made in Germany, Adjusted reach to provide larger depth range, Three jaw design ensures the load is distributed evenly. The 3-armed lug puller "Economy" with oscillating and height-adjustable puller legs is used for pulling off bearings, gears and washers in all common sizes for crafts, workshops and industry. The oscillating and curved puller legs adapt to any installation situation and can be used universally due to the adjustable clamping depth. The 3-arm design guarantees an even load distribution and thus a particularly secure hold on the part to be extracted. Range of Application: ...

Forcing screw for 10 ton puller: Length: 10-9/16" Diameter & Thread: 3/4-10UNC-2A Hexagon: 3/4" Capacity: 10 tons Material (SAE): 2132M Hardness (HRC): 42-46

These pullers are mainly for the automotive industry where parts like pulleys, gears, and large sprockets are used in assembly lines, making their extraction easier and safer. Treated steel forcing screw; features a hex head that can be turned with socket and ratchet. Has a floating tip that exerts the extraction force. Forged head made of high-resistance steel. Die-cut and hardened metal clip holds the jaws to the puller's body. Interchangeable and adjustable jaws, great for different types of extractions. WITH OUT METAL BOX

Made in Germany, Reversible jaws can be used for both external and internal applications, Two jaw design for space-saving applications. The 2-arm lug puller with oscillating and reversible puller legs is used for centric pulling off of bearings, gears and washers in all common sizes for handicraft, workshop and industry. It can be used to loosen any component that sits on a shaft and is freely accessible from the outside. The oscillating puller legs with adjustable clamping depth can be used on both sides. The claw shape differs depending on the version. Range of Application: For centric ...

Made in Germany, Grease hydraulic spindle power, Adjusted reach to provide larger depth range, Two jaw design for space-saving applications. The heavy, 2-arm lug puller with oscillating, height-adjustable puller legs and grease-hydraulic spindle is used for centric pulling of large, particularly tight-fitting bearings, gears and discs in all common sizes for crafts, workshops and industry. The grease-hydraulic spindle achieves a pulling force of 15 tonnes. It can be used to loosen any component that sits on a shaft and is freely accessible from the outside. The mechanical spindle can be ...
