Features:
- 1000 watt low frequency inverter
- 3000 watt surge for 20 seconds 300% surge capability
- Battery Priority Selector
- Terminal Block
- GFCI outlet
- Marine Coated and Protected
- Multi Stage Smart charger 20 Amp
- remote panel available
- auto frequency
- 10msec typical transfer time
- optional 25W power save mode
- 7 battery type settings for charger
Inverter Output Specifications:
- Continuous Output Power: 1000 Watts
- Surge Rating: 3000 Watts (20 Seconds)
- Output Waveform: Pure Sine/Same as input (Bypass Mode)
- Nominal Efficiency: >88% (Peak)
- Line Mode Efficiency: >95%
- Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
- Typical Transfer Time: 10ms (Max)
- THD: < 10% DC
Input Specifications:
- Nominal Input Voltage: 12.0Vdc
- Minimum Start Voltage: 10.0Vdc
- Low Battery Alarm: 10.5Vdc-11.0Vdc
- Low battery Trip: 10.0Vdc-10.5Vdc
- High Voltage Alarm: 16.0Vdc
- Low battery Voltage Restart: 15.5Vdc
- Idle Consumption: <0.5 amps AC
- Power Saver Mode Idle Consumption: <1 amps AC
Charger Specifications:
- Output voltage: Depends on battery Type
- Charger Rate: 20A
- Over Charge Protection Shutdown 15.7V
- Selectable Charge setting based on battery type
- Adjustable charge current off-20%-100%
- Four Stage Smart Charger
Transfer Switch Specifications:
- 30 amp automatic transfer switch
- 10 ms (max)
Dimensions
- Unit Weight: 35 lbs.
- Unit Size L x W x H: 15.0 x 8.59 x 7.05 inches
- Shipping Weight: 39 lbs.
- Shipping L x W x H 20.5 x 12.40 x 11.81 inches
