Features:
- Listed to UL 1741-SA I CSA 22.2 No.107-01 I UL1998 I UL1699B
- Stackable (Max 6)
- Direct 3 string PV input
- IP65 NEMA4X rated for outdoor installation
- 10 year warranty
- Customizable DC input voltage for various battery types including lithium and lead
- Free USA based tech support
- Wide programmable voltage input range
- Generator input for backup 240VAC
- Wide PV input voltage range
- Load sharing
- Isolated emergency backup output for defined loads
- Configurable charge and load times based on local utility recommendations
- Loaded with safety features
- Large 5-inch color LCD
- RS485, CAN, Wi-Fi, 4G
- Extremely efficient
- FCC Part 15 Class B
- Max Input Power (kW) : 6.9
- Max PV Voltage (V) : 660
- MPPT Range (V) : 80-550
- Normal Voltage : 360
- Startup Voltage : 100
- Max Input Current (A) : 15.5 x 2
- Max Short Current (A) : 26 x 2
- Max Charge/Discharge Power (kW) : 6.9 | 6.9
- Max Charge/Discharge Current(A) : 50
- Battery Voltage (V) : 230
- Battery Voltage Range(V) : 80- 495
- Battery Type : Lithium | Lead
- Max Continuous Power(kVA) : 4.6
- Max Continuous Current(A) : 19.5 | 22.5
- Nominal Grid Voltage (V) : 211 to 264 @ 240 | 183 to 229 @ 208 (not 3 phase, split phase)
- Nominal Grid Frequency (Hz) : 60
- Output Power Factor : .99 adjustable
- Current THD(%) : <3
- Max Continuous Power(kVA) : 4.6
- Max Continuous Current(A) : 19.5 | 22.5
- Max Peak Current (A)(10 min) : 28.8 | 33.2
- Max Peak Power(kVA)(10 min) : 6.9 | 6.9
- Nominal AC Voltage L-L(V) : 240 | 208 (not 3 phase)
- Nominal AC Voltage L-N(V) : 120 | 120
- Nominal AC Frequency(Hz) : 60
- Switching Time(ms) : <10
- Voltage THD(%) : <3
- CEC Efficiency(%) : 97
- Max Efficiency(%) : 97.6
- PV to Battery Efficiency(%) : 98.1
- Battery to AC Efficiency(%) : 96.8
- PV Reverse Polarity Protection : YES
- Battery Reverse Polarity Protection : YES
- Over Current/Voltage Protection : YES
- Anti-Islanding Protection : YES
- AC Short Circuit Protection : YES
- Residual Current Detection : YES
- Ground Fault Monitoring : YES
- Insulation Resister Detection : YES
- PV Arc Detection : YES
- Rapid Shut Down/Disconnect : YES
- Enclosure Protect Level : IP65 | NEMA4X
- Cooling : Natural Convection
- Relative Humidity : 0-100%
- Operating Temperature Range : -25 to 60C | -77 to 140F
- Operating Altitude : < 4000 m | <13123 ft. without derating
- Noise Emission (dB) : <25
- Stanby Consumption (W) : <10
- Mounting : Wall Bracket
- Communication with RSD : SUNSPEC
- Display & Communication Interfaces : Full Color LED, RS485, CAN, Wi-Fi
- Certification & Approvals : UL 1741 SA | CSA 2202 No. 107-01 |UL 1998 | Rules21 | HECO Rule 14 | IP65 | CEC
