The MDR2i OLED Smart controller may be connected to mobile phones, tablets, notebooks, or computers. The controller can be used as an access point or can be connected to a Wi-Fi network. Compressor features and parameters may be entered and controlled comfortably along with remote monitoring.
The powerful 2.0 HP motor operates at only 1680 RPM creating less noise, vibration and creating less wear. The oil-free dual piston pump system is engineered for longevity, high performance and durability. The SP-9421 motor/pump is tested for a minimum pump life of 3000 hours before service. 30% more life before repair. The SP Series of ultra quiet air compressor motors have been designed to increase duty cycle and allow for longer continuous run times.* The large 10.0 gallon steel air tank is only 91 lbs. The 80% Air Dryer is specially designed to remove the water vapor from the air to protect sensitive tools and machinery. To dry the air from the air compressor an Aftercooler and 80% Air Dryer are utilized. The aftercooler is a heat exchanger for cooling the discharge air from the air compressor. The water vapor from the compressed air is condensed into liquid form and pushed into the Air Dryer.
The California Air Tools EZ-1 automatic drain valve has been designed to eliminate manually draining your air compressor air tank. The manually set timer allows you to set the time for both the frequency and duration of the draining process. Designed for the person looking for Power, 80% Dry Air and Less Service with at Least 30% less noise! ideal for dental, milling, bio-tech, manufacturing, packaging, restaurant and general engineering applications.
Features:
- Oil-Free Pump – Cleaner air for better tool operation
- Regulated output pressure gauge
- Pressure Regulator (0-120 PSI)
- One - Female Industrial "Push to Connect" quick connector (1/4" NPT)
- Easy Start Valve - For less starting amperage
- Thermal overload Protector
- Working pressure 90-120 PSI (±5 PSI). Adjustable up to 105 PSI kick-on; 130 PSI kick-off maximum
- 110v/60 Hz
- Low amp draw - Only 14.0 Amps
- Tank fill rate from empty to full - 130 Seconds
- Recovery time from 95 PSI to 125 PSI - 40 Seconds
- Duty Cycle - 70/30*
- L (16") x W (23") x H (35")
- 91 pounds
- Non-ASME air tank
- Air Dryer - Includes activated alumina desiccant with a 4000 hour life. Activated Alumina is used in air prepurification (due to it's high water and carbon dioxide adsorption capacity) and adsorption of sulphur compounds
- EZ-1-2321 auto drain valve factory installed
- 1 Year Limited Warranty
