Features:
- Flatter head installed on machine for sanding uneven surfaces
- Aluminum drum included for drum sanding
- Open Stand included
- Variable Feed Speed with INTELLISAND™
- Variable head speed needed when using brush heads
- Optional Wire and Nylon brush heads available for purchase
- Simple alignment feature Just one nut will adjust the conveyor to parallel the sanding head, making aligning the conveyor to the sanding head fast and easy
- Indexed alignment setting has narrow and wide stock. When sanding stock wider than 19", the index lever will properly adjust the conveyor for flawless wide sanding
- Easy height adjustments A thrust bearing below the handle and a nut positioned above prevents the drum from moving out of the set position while sanding. No backlash or slop in the height adjustment mechanism allowing easier and smoother height adjustments
- Extra-wide conveyor to properly support stock over 19" wide. The conveyor table is 22" wide to add support to the work piece
- Drum will never go "out of alignment" The drum carriage is bolted to the base, preventing any movement or alignment issues
- INTELLISAND™ Technology: Automatically adjusts conveyor speed based on load
- Prevents gouging, damaging or burning stock
- Provides consistent finish even with varying grain pattern and density
- Greatly increases abrasive planing and dimensioning speed
- Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections for no "flex" in conveyor, guaranteeing flatness to less than .010" across the width of the sander
- Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
- Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and overlap
- Easiest access to abrasive fastening system of any drum sander! Extra wide space to access fasteners to eliminate need for special tools
- Self-cooling drum prevents overheating and extends abrasive life
- Tension rollers are adjustable in height and hold down pressure, eliminating snipe
- Excellent dust extraction as dust cover is formed to shape of drum Metal, not plastic, is formed to maximize air flow and dust extraction
- Heavy-duty cast iron construction for strength, rigidity and reduced vibration
- Maximum Width (in): 38" (two passes)
- Minimum Length (in): 5-1/2"
- Dimensions (H x W x D): 24" x 40" x 24"
- Drum Speed: 1740 RPM
- Dust Hood: 1 – 4" Vacuum port, min. 600 CFM Recommended
- Conveyor Motor: 43in.-lb torque, direct drive D.C. motor, ranged variable 0-10 FPM
- Drive Motor (TEFC): 1-3/4"
- Power Requirements: 110V 15 Amp
- Maximum Thickness (in): 4" (Varies With Application)
- Minimum Thickness (in): 1/32"
- Open Stand Footprint: 21" x 36"
- Net Weight: 264 lbs.
- Ships Without Cord Or Plug
