Features:
- Flush mount design
- 12V – 360 Watts & 24V – 720 watts
- Small and compact ideal for small areas
- Conformal coated for marine environments
- Works with lithium, Gel AGM and lead acid
- Efficient and uses the latest PWM charging technology and state of charge monitoring, adjusts charging based on battery voltage prolonging overall battery life
- LCD displays key information such as battery voltage, solar panel voltage, solar panel charging current and battery status
- PV input, battery output ports (DC load port on 10amp)
- USB outlet
- Included mounting bracket for flat mount
- 55Voc max
- Rated PV input:
- 12V – 360 Watts
- 24V – 720 watts
- Maximum battery current: 30 amps
- Max PV open circuit voltage: 55V
- Self power consumption: <2 watt
- Efficiency: 97%
- Protections: overload, short circuit, high voltage, high temperature, low voltage and auto correct
- Optimal cooling case design
- Battery types: gel, sealed, AGM, flooded, lithium, user defined (adjustable voltage)
- 3 Stage charging: boost, float and equalize
- Boost charge voltage: sealed 14.4V, AGM/Gel 14.2V, flooded 14.6V, lithium user defined 10-15V
- Float charge voltage: sealed/AGM/Gel 13.8V, flooded 13.8V, lithium NA defined 10-15V
- Equalize charge voltage: sealed 14.6V, AGM/Gel NA, flooded 14.8V, lithium NA user defined 10-15V
- Low voltage reconnection: 12.6V
- Low voltage disconnect voltage: 11.1V (10.5-12.5V adjustable)
- Enclosure: IP32
- Cooling: heatsink
- Humidity: 100% non-condensing
- Temperature compensation: -5mV⁰C
- Temperature range: -35⁰C to 45⁰C or -31⁰F to 113⁰F
- Conformal coated for marine environments
- Unit weight: .5 lb.
- Dimensions: 5.125"W x 3.5"L x .75"H
- Warranty: 2 year
