Vibra Systems FMD-9 - Compression Mount 1200 Lbs. Max Load 1/2" Deflection

Type "X-100" series Spring Mounts with one inch deflection solves troublesome vibration problems. These mounts are preferred over most rubber mounts due to the high static deflection of the spring. "X-100" series spring mounts are designed for noise and vibration control applications in critical areas on concrete or wooden floors. The mount features a two piece cast iron housing for the spring. The mounts are provided with slotted mounting holes with a non-skid elastomeric acoustic pad on the base for easy bolting to the floor. Resilient elastomeric snubbers on the inner panels prevent ...

Wherever bolting is to be avoided and minor non-critical vibration conditions exist. (pumps motors air-conditioning units generators etc.). Material: Special Rubber Maximum Loading: 60 Ibs/sq. in Working range: 15 to 55 Ibs/sq. in. Features: Molded metalic rib construction for relibilty and longevity No bolting required Simple field installation

Steel springs reduce vibration transmission most efficiently as performance improves with larger deflections. Minimum deflection is 0.75" which increases with heavier loadings. Spring deflections are 2 - 6 times higher than the rubber products. IMF Unhoused Simple Spring Mount works best for indoor applications on lightweight equipment that does not have to be completely level and does not need to be bolted down. Max Load 130-200 LBS. 5-3/4"L x 2-1/8"W x 4-1/2"H Overall Dimensions.

Vibra Systems AVH-2-70 - Antivibration Rubber Hanger 165 Max Lbs 1/2" Deflection Blue HND Series hangers are neoprene elements housed in sturdy steel. Elements include top and bottom steel plates for uniform load distribution. "D" stands for double deflection for neoprene elements, single deflection element are ineffective for vibration isolation and are not available. All elements are color coded for ease of identification. HND Series hangers are used for hanging small machines like fan coil units and fans etc.

HSA series spring hangers are large diameter steel springs housed in rectangular steel housings. Assembly incorporates dual (steel & elastomer) washers for uniform load distribution and high frequency isolation. Springs have a 50% additional travel to solid load as per the ASRAE recommendations. Spring hangers are used for hanging fan coil units, air handling units, fans, pipes, and ducts. These spring hangers are normally used for critical areas where noise and vibration both need to be controlled.
